| Printing Characteristics |
| Print Length |
Max 30”(762mm) |
| Print Method |
Direct Thermal / Thermal Transfer |
| Print Speed |
2~ 6ips(51~152mm/s) |
| Print Width |
Max 6.6”(168mm) |
| Resolution |
203 dpi(8 dots/mm) |
|
| Media Characteristics |
| Media Core Diameter |
Core size: 1.5” ~ 3” (38~76mm) ID |
| Media Roll Diameter |
Max roll capacity(OD): 8”(203mm) |
| Media Sensor |
Media gap & black line Reflective sensor x 1(Movable) &Transmissive sensor x 1(Movable) / Head open switch / Ribbon end sensor |
| Media Thickness |
Thickness: 0.0025”~0.01”(0.0635~0.254mm) |
| Media Type |
Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper and fabric label |
| Media Width |
Max Width: 6.3”(160mm)Min Width:1”(25.4mm) |
|
| Ribbon Characteristics |
| Ribbon Length |
Ribbon Length: max 360m |
| Ribbon Roll Diameter |
Ribbon roll – max OD: 2.5”(63mm) |
| Ribbon Type |
Wax/Resin, Resin(Ribbon Wound Ink-side in) |
| Ribbon Width |
Ribbon Width: 1”~6.1” |
| Core Inner Diameter |
Core size – ID: 1”(25.4mm)Wax |
|
| Performance Characteristics |
| Display |
Back-lit LCD Display 16 x 2-line, |
| Indicators |
LED indicator x 3(Ready/Media/Ribbon) |
| Interface |
Operation interface: Button x 3 (Feed(Config.)/Pause(Calibr.)/Cancel(Reset)Communication Interface:Centronics Parallel, RS-232 |
| Memory |
2MB DRAM1MB Flash ROM |
| Processor /CPU Type |
32 bit RISC microprocessor |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D: PPLA:Code 39, UPC-A, UPC-E, Code 128 subset A/B/C, EAN-13, EAN-8, HBIC, Codabar, Plessey, UPC2, UPC5, Code 93, Postnet,UCC/EAN-128, UCC/EAN-128 K-MART, UCC/EAN-128 Random Weight, Telepen, FIM, Interleave 2 of 5 (Standard/with modulo 10 checksum/with human readable checkdigit/with modulo 10 checksum & shipping bearer bars), GS1 Data bar (RSS) |
|
2D:PPLA:MaxiCode, PDF417, Data Matrix (ECC 200 only),QR code, Composite Codes, Aztec Barcode, Micro PDF417 |
| Character Sets |
Internal character sets standard |
| Character Size |
5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) |
| Enlargement & Rotation |
Internal fonts are expandable up to 24×244 direction 0° ~ 270° rotation |
| Graphics |
PPLA: PCX, BMP, IMG and HEXformats |
|
| Software |
| Driver / Utility |
Printer Utility?Font Utility |
| Emulation |
PPLA |
| SDK |
Windows Driver (Windows XP/ Vista/ 7/8) BarTender® from Seagull Scientific |
|
| Environment Characteristics |
| Operation Environment |
Operation Temperature: 40°F~100°F (4°C~38°C), 0% ~ 90% non-condensing |
| Storage Environment |
Storage Temperature: -4°F~122°F (-20°C~50°C) |
| User Options |
Cutter, Dispenser Kit, Stacker, RTCCard, 2MB Asian Font Card(TraditionalChinese, Simplified Chinese, Koreanand Japanese), ArgoKee |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
W 310mm x L 445mm x H 260mm |
| Power Source |
Internal Universal Power Supply100 ~ 240 VAC, 2.5A, 50/60 Hz |
| Weight |
14.5 kgs |
