| Printing Characteristics |
| Print Length |
6 ~ 1,000mm |
| Print Method |
Direct Thermal |
| Print Speed |
SLP-D420: Up to 6 ips (152 mm/s) /SLP-D423: Up to 4 ips (100 mm/s) |
| Print Width |
SLP-D420: Up to 104 mm / SLP-D423: Up to 105.7 mm |
| Resolution |
SLP-D420: 203 dpi / SLP-D423: 300 dpi |
|
| Media Characteristics |
| Media Roll Diameter |
Up to 130 mm |
| Media Sensor |
Transmissive, Reflective (adjustable), Head open |
| Media Thickness |
0.06 ~ 0.20 mm |
| Media Type |
Gap, Black Mark, Notch, Continuous, Fan-Fold |
| Media Width |
25 ~ 116 mm |
| Supply Method |
Easy Paper Loading |
|
| Performance Characteristics |
| Interface |
Triple InterfaceStandard: Serial+Parallel+USB V2.0 HSOptional: Serial+Ethernet+USB V2.0 HS |
| Memory |
8MB SDRAM, 4MB FlashROM |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D: Coda Bar, Code 39, Code 93, Code 128, EAN-8,EAN-13, IMB, Interleaved 2-of-5, ITF, UCC/EAN-128, UPC-A, UPC-E |
|
2D: Data Matrix, MaxiCode, PDF417, QR Code |
| Character Sets |
10 SLCS Resident Bitmap FontsOne SLCS Resident Scalable Font23 Code Page |
| Graphics |
Supporting user-defined fonts, graphics, formats, and logos |
|
| Software |
| Driver / Utility |
Windows Driver, Linux CUPS Driver, Mac Driver, Virtual COMUSB/Ethernet Driver, Utility Program, Label Artist™ |
| Emulation |
SLCS, BPL-Z™, BPL-E™ |
| SDK |
Android SDK |
|
| Environment Characteristics |
| Humidity |
Operating: 10 ~ 80% RH / Storage: 10 ~ 90% RH |
| Operating Environment |
Operating: 0 ~ 40 °C (32 ~ 104 °F) / |
| Storage Environment |
Storage: -20 ~ 60 °C (-4 ~ 140 °F) |
| User Options |
Ethernet, Peeler, Auto Cutter, External Paper Supply |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
194 x 243 x 171 mm (7.63 x 9.56 x 6.73 inch) |
| Power Requirements |
EnergyStar Certified, External Power Adaptor 100-240V AC, 50/60Hz |
| Weight |
2.15 kg (4.73 lbs.) |
