| Performance Characteristics |
| CPU/Processor |
MICROPROCESSOR XScale™ PXA310 @ 624 MHz |
| Indicator |
Good-Read Feedback: Datalogic’s patented‘Green Spot’ technology |
| Interface |
Electrical: integrated RS-232 up to 115.2 KbpsUSB: integrated mini USB connector, Host 1.1 andClient 2.0 |
| Memory |
System Flash: 256 MB (including Backupdirectory for user data & programs permanentstorage)System RAM: 128 MB |
| Operating System |
Microsoft Windows CE 5.0 with MicrosoftWordPad and Internet Explorer 6.0Microsoft Windows Mobile® 6.1 with Mobiletools: Outlook, Word Mobile, Excel Mobile,PowerPoint Mobile, One Note Mobile andInternet Explorer Mobile 6.0 |
| Software |
security Wavelink CE Secure, Wavelink CertificateManager |
|
TERMINAL EMULATION Wavelink Terminal Emulation, WavelinkConnectPro |
|
APPLICATIONS Vo-CE™ (voice recognition), Wavelink® SpeakEasy(voice recognition)Pal™ Application Library prelicensed |
|
DEVELOPMENT Datalogic SDK™ (C/C++, .NET, JAVA), Wavelink®Studio™, DL Mobility Developer Assistant™, MCLCollection™, Java Virtual Machine |
|
CONFIGURATION & MAINTENANCE Wavelink Avalanche® prelicensed, AvalancheRemote Control™, Avalanche Secure Plus™,Datalogic Firmware Utility (DFU); DatalogicDesktop Utility (DDU); Datalogic ConfigurationUtility (DCU) |
|
| Communication Modules |
| WLAN Radio |
Summit IEEE 802.11 a/b/gFrequency range: Country dependent, typically2.4 and 5.2 GHz |
| WLAN Security |
CCX v4 Security |
| WPAN Radio |
Bluetooth® Wireless Technology IEEE 802.15Class 2 with EDR |
|
| Data Capture Characteristics |
| Decode Capabilities |
stacked codes Micro PDF, PDF417 |
|
1D / linear codes Auto discriminates all standard 1D codesincluding GS1 DataBar™ linear codes. |
|
2D Codes Aztec Code, Data Matrix, Intelligent Mail,Maxicode, QR Code, Micro QR, UPU FICS,USPS 4CB |
|
postal codes Australian Post, Japan Post, KIX Code; PLANET,POSTNET, KIX Code, Royal Mail Code (RM4SCC) |
| Imager |
Scan Rate: 60 frames/sec maximum |
|
Minimum Resolution: Linear codes at 4 mils;2D codes at 5 mils |
|
imaging Depth of Field: 4.3 to 35.0 cm / 1.7 to 13.8 in,depending on bar code density |
| Laser |
Scan Rate: 104 +/- 12 scans/sec |
|
Minimum Resolution: 0.10 mm / 4 mils |
|
Depth of Field: 5 to 64 cm / 2 to 25 in, dependingon bar code density |
| Scanner Systems |
Laser&imaging |
|
| Power Specifications |
| Battery |
Removable battery pack with rechargeable Lipolymer/ Li-ion batteries; 3.7 V 1100/2000 mAh(4.07/7.40 Watt hours) |
|
| Environment Characteristics |
| Drop Specification |
Withstands drops from 1.2 m (4 ft) onto concrete |
| Environmental Sealing |
particulate and water SEALING IP54 |
| Operating Temperature |
0 to 50 ºC / 32 to 122 ºF |
| Real Time Clock |
Time and date stamping under software control |
| Storage Temperature |
Storage/Transport: -20 to 70 ºC / -4 to 158 ºF |
|
| Physical Characteristics |
| Audio |
Speaker, integrated microphone, vibrator |
| Dimensions (W x H x D) |
LAN/Batch: 15.2 x 5.5 x 4.0 cm / 6.0 x 2.2 x 1.6 in |
| Display |
Reflective TFT daylight readable color displayQVGA, 240 x 320 pixels, 2.2 in diagonal, 64 Kcolors, backlight, touch screen |
| Expansion Slot |
Micro SD card slot compatible with SDHC cards,user-accessible |
| Keypad |
23 keys, 5-position joystick, backlit keyboardstandard |
| Weight |
230 g / 8.11 oz including standard battery |
|
| Options |
| Regulatory Approvals |
The product meets necessary safety and regulatory approvals for its intended use. |
| User Options |
environmental compliance Complies to EU RoHSLASER CLASSIFICATION VLD – Class 2 IEC/EN60825-1; Compliant with 21CFR 1040.10 except for deviations pursuant tolaser notice No. 50 dated June 24, 2007.LED CLASSIFICATION Exempt Risk Group IEC/EN62471 |
