| Performance Characteristics |
| CPU/Processor |
PXA320, 800MHz |
| I/O Ports |
RS-232/USB 2.0 host and client/audio out/Ethernet/charging connector |
| Memory |
128MB SDRAM, 128MB Flash; 1GB or 4GB SD-card expansion |
| Operating System |
Microsoft® Windows® CE 5.0 Professional or Microsoft® Windows® Mobile 6.5 |
|
| Communication Modules |
| GPS |
GPS receiver |
| WLAN Antennas |
Internal diversity antenna |
| WLAN Radio |
WLAN 802.11 b/g, 802.11 a/b/g |
| WLAN Security |
Authentication: Support for a full range of 802.1X (EAP) types, including EAP-TLS, PEAP-MSCHAPv2,PEAP-GTC, LEAP, and EAP-FASTEncryption: Support for Static, pre-shared, and dynamic encryption keys, 40-bit and 128-bit keys, WEP, WPA(TKIP), and WPA2 (AES) Encryption Methods |
| WPAN Radio |
Bluetooth® 2.0 + EDR, class II |
| WWAN Radio |
GSM, GPRS, Edge |
|
| Data Capture Characteristics |
| Decode Capabilities |
Reads standard 1D and 2D symbologies |
| Imager/Scanner |
Near-Far Range Laser (Lorax), Standard Ranger Laser, 2D imager |
|
| Power Specifications |
| Battery Life |
3.5 hour battery life at -30C (scanning and sending data over WLAN and Bluetooth every 10 seconds) |
| Standard Battery |
Standard temperature – Li-ion, 11.1V, 2,400 mAhLow temperature – Li-ion, 11.1V, 2,200 mAh |
|
| Environment Characteristics |
| Drop Specification |
Withstands multiple 6’ (1.8 m) drops to concrete |
| Electrostatic Discharge (ESD) |
15KV Air discharge, 8KV contact discharge |
| Environmental Sealing |
Independently certified to meet IP67 standards for moisture and particle resistance |
| Operating Temperature |
-22° to +122°F (-30° to +50°C) w/ heaters |
| Relative Humidity |
5 to 100% relative humidity condensing at 104°F (40°C) |
| Storage Temperature |
-4° to +158°F (-20° to +70°C) |
| Tumble Specification |
2,000 (1m) tumbles per IEC 60068-2-32 specification |
|
| Physical Characteristics |
| Audio |
Microphone, Speaker with adjustable volume control |
| Dimensions (W x H x D) |
9.9? x 3.9? x 2.7? (251mm x 99mm x 69mm) |
| Display |
3.7? (94 mm) QVGA (240×320), transflective |
| Keypad Options |
Backlit 62-key alphanumeric, 38-key numeric-alpha |
| Touch Panel |
Resistive touchscreen with stylus with heater |
| Weight |
2.1 lbs. (34 oz.) with scanner, 802.11, Bluetooth and handstrap |
