| Printing Characteristics |
| Print Method |
Direct Thermal/Thermal Transfer |
| Print Speed |
Selectable up to 8 ips (203.2 mm/sec) for 203 dpi6 ips (152.4 mm/sec) for 300dpi |
| Print Width |
203 dpi – max. 56 mm (2.2 in); 300 dpi – max. 54 mm (2.1 in) |
|
| Media Characteristics |
| Label Length |
Min. 6.35 mm (.25 in) |
| Media Core Diameter |
Min. 25.4 mm (1 in)Max. 38.1 mm (1.5 in) |
| Media Roll Diameter |
127 mm (5 in) |
| Media Thickness |
0.06 mm (0.003 in) to 0.15 (0.006 in)Optional thick media spring kit for media up to 0.20 mm (0.008 in) |
| Media Width |
Max 60 mm (2.36 in), Min 15 mm (.59 in) |
|
| Ribbon Characteristics |
| Ribbon Length |
0.5”: 91 m (3,588 in)1.0”: 300 m (11,811 in) |
| Ribbon Type |
A wide selection of widths and formulations available |
| Ribbon Width |
1.0” – ribbon only, core width must be111 mm (4.37 in |
|
| Performance Characteristics |
| Interface |
USB Device Type B connector v.2.0 high speed, USB Host Type A connector v.2.0 high speed Field Installable: Ethernet 10/100 Mbps module, Dual radio module (802.11 b/g/n and Bluetooth® V2.1), USB to Serial adapter (RS-232), USB to Parallel adapter |
| Memory |
128 MB Flash, 128 MB RAM (DDR2)Up to 32 GB via user USB thumbdrive |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
All major 1-dimensional bar code symbologies are available, plus 2-dimensional and composite codes: Aztec, Code 16K, Code 49, Data Matrix, Dot Code, EAN-8, EAN-13, EAN.UCC 128, Grid Matrix, HIBC 39, HIBC 128, MaxiCode, MSI (modified Plessey), PDF417, Micro PDF417, Planet, Plessey, Postnet, QR-Code, RSS-14 (variations) |
| Character Sets |
English and Extended Latin, Cyrillic, Greek, Turkish, Hebrew, Arabic, Baltic, Baltic RIM, Vietnamese, Thai and more with Monotype™ Universal Font Scaling Technology (UFST) and WorldType Layout Engine (WTLE). |
| Graphics |
Native support for BMP, GIF, PCX and PNG graphics formats. |
|
| Software |
| Driver / Utility |
InterDriver™ Windows printer driver |
| SDK |
C# for Printers IPLDirect ProtocolZSim (ZPL) DSim (DPL)XML enabled for SAP® AII and Oracle® WMS |
|
| Environment Characteristics |
| Humidity |
10–80% RH non-condensing |
| Operating Environment |
+5° to +40°C (+40° to +104°F) |
| User Options |
Support for downloading TrueType and TrueType-based OpenType fonts and user-defined fonts. |
|
| Physical Characteristics |
| Power Requirements |
100–240 V AC/50–60 Hz, 1.5 A |
|
| Options |
| Regulatory Approvals |
CE, FCC Class A, cULus, UL, GS, TUVGS, BSMI, D Mark, cUL, CCC (China), KCC (South Korea), C-TICK (Australia/NZ) |
