| Performance Characteristics |
| CPU/Processor |
600 MHz, ARM 11 processor, MSM 7627 |
| Interface |
Motorola Enterprise UI; customizablehomescreen, enhanced dialer and enterprisecamera solution |
| Memory |
256MB RAM/1GB Flash |
| Motorola Interactive Sensor Technology |
Motion-sensor: 3-axis accelerometer that enables motion-sensingapplications for dynamic screen orientation andpower management |
| Notification |
Programmable LEDs; Audio notifications;Vibrator alerts |
| Operating System |
Windows Mobile 6.5.3 Professional |
| Vibration/Thermal Shock |
MIL-STD 810G Method 514.5, figure 514.5C-1; 1hour per axis/-20° F to 158° F/-20° C to 70° C rapid transition |
|
| Communication Modules |
| Integrated GPS |
Integrated standalone or Assisted-GPS (A-GPS) |
| Network Communications |
I/O: Micro USB 2.0 High Speed (host and client) |
| Voice and Audio |
Audio: VoWWAN; VoWLAN; PTT and TEAM Expressready; rugged audio connector; high-qualityspeakerphone; support for wired and wireless(Bluetooth) headsets; support for PTT headsets,handset and speaker phone modes |
| WLAN Antennas |
Internal antenna |
| WLAN Radio |
Tri-mode IEEE® 802.11a/b/gData Rates Supported: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48 and 54 MbpsOperating Channels: Chan 36-165 (5180 – 5825 MHz)Chan 1-13 (2412-2472 MHz)Chan 14 (2484 MHz) Japan onlyActual operating channels/frequencies dependon regulatory rules and certification agencyVoice Communications: Voice-over-IP ready, Wi-Fi™-certified, IEEE802.11a/b/g direct sequence wireless LAN |
| WLAN Security |
WPA2 (Personal or Enterprise); 802.1x; EAP-TLS;TTLS (CHAP, MS-CHAP, MS-CHAPv2, PAP or MD5);PEAP (TLS, MSCHAPv2, EAP-GTC); LEAP, EAP-FAST(TLS, MS-CHAPv2, EAP-GTC) |
| WPAN Radio |
Bluetooth: Class II, v2.0 with Enhanced Data Rate (EDR);integrated antenna |
| WWAN |
Radio: Dual 3.5G: GSM HSDPA/HSUPA and CDMAEVDO Rev A broadband for voice and dataFrequency Band: UMTS/HSDPA and HSUPA: 850, 1900 and 2100 MHzGSM/EDGE: 850, 900, 1800 and 1900 MHzCDMA/EVDO Rev A: 850 and 1900 MHzInternal antennas: primary and diversityAntenna: Internal antennas: primary and diversity |
|
| Data Capture Characteristics |
| Data Capture Options |
1D and 2D bar codes; photographs; video;signatures; documents |
| Decode Capabilities |
Bar Code Scanning: Integrated 1D and 2D decoding |
|
| Power Specifications |
| Battery Performance |
Standby Time: 250 hours standard battery500 hours extended batteryTalk Time: 6 hours (WAN) standard battery12 hours extended battery |
| Extended Battery |
Extended: Rechargeable Lithium Ion 3080mAhbattery @ 3.7 V |
| Standard Battery |
Standard: Rechargeable Lithium Ion 1540mAhbattery @ 3.7 V |
|
| Environment Characteristics |
| Altitude |
(-1,200 ft. to 15,000 ft). operational15,000 ft. shippingKeyboard/Side Buttons: 1 million presses |
| Device Security |
Biometric (finger swipe) and PIN code |
| Drop Specification |
Military Standard (MIL-STD) 810G 4 ft./1.22 mdrop specification; 3 ft./0.91 m drop tovinyl covered concrete across the operatingtemperature range (36 drops at 32° F/0° C, roomtemperature and 104° F/40° C) |
| Electrostatic Discharge (ESD) |
±15kv Air discharge, ±8kv direct discharge,±8kv indirect discharge |
| Environmental Sealing |
Meets and exceeds IP42 sealing |
| Humidity |
5 – 95% non-condensing |
| Keyboard/Side Buttons |
1 million presses |
| Operating Temperature |
32° F to 104° F/0° C to 40° C |
| Storage Temperature |
-40° F to 158° F/-40° C to 70° C |
| Tumble Specification |
150 1.65 ft./0.5 m tumbles (equivalent to 300consecutive drops) at room temperature; meetsand exceeds applicable IEC tumble specifications |
