| Printing Characteristics |
| Print Length |
49.2″ (1,249mm) L |
| Print Method |
Direct Thermal/Thermal Transfer |
| Print Speed |
2 to 6 ips (50 to 150mm/s) |
| Print Width |
4.09″ (104mm) W x |
| Resolution |
203 dpi (8 dpmm) |
|
| Media Characteristics |
| Media Roll Diameter |
0.6″ – 49.2″ (15mm – 1,249mm |
| Media Sensor |
Reflective Sensor (for use with pre-printed marks)Adjustable See-Through Sensor (for die-cut label with gap) |
| Media Thickness |
0.003″ – 0.010″ (0.08mm – 0.26mm) |
| Media Type |
Die-Cut Labels, Waste Removed, Roll, 0.125″ gap |
| Media Width |
1.125″ – 4.52″ (28.6mm – 115mm |
|
| Ribbon Characteristics |
| Ribbon Length |
Up to 1476′ (450 m) |
| Ribbon Width |
0.98″ – 4.37″ (25mm – 111mm) |
|
| Performance Characteristics |
| Interface |
IEEE1284 (Parallel); RS232C Serial (25-pin); USB, LAN (10BaseT/100BaseTX auto-switching |
| Memory |
4MB Flash ROM / 16MB SDRAM |
| Processor/CPU Type |
32-bit RISC |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:UPC-A/E, EAN-8, EAN-13, Code 39, Code 93, Code 128, Codabar, MSI, Bookland, Industrial 2/5,Interleaved 2/5, Matrix 2/5, Postnet™, GS1-128, GS1-DataBar™, Intelligent Mail® Barcode (IMB) |
|
2D:PDF417, Micro PDF417, Truncated PDF417, Maxicode™, Data Matrix, QR Code, Composite Symbology |
| Enlargement & Rotation |
XU, XS, XM, XB, XL, Outline, OCR-A, OCR-B CG Times (Serif), CG Triumvirate (San Serif |
|
| Environment Characteristics |
| Operation Environment |
41° – 104°F (5° – 40°C); 15% – 85% RH, non-condensing |
| Storage Environment |
0° – 140°F (-20° – 60°C); 15% – 85% RH, non-condensing |
| User Options |
Wireless LAN (802.11g), RS422/485EXT Port (Applicator Interface) 14-Pin Centronics style connector |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
13″ (330mm) W x 10.7″ (271mm) D x 10.6″ (270mm) H |
| Power Source |
100 – 240 VAC (+/- 10%); 50/60 Hz; Auto-Switching |
| Weight |
Weight: 21.4 lbs. (9.7Kg) Standard Configuration |
|
| Options |
| Regulatory Approvals |
FCC Class B, MET (UL60950-1/CSA60950-1), CE |
