| Printing Characteristics |
| Print Method |
Direct Thermal/Thermal Transfer |
| Print Speed |
250mm/sec (10ips) |
| Print Width |
(WxP): 80 x 240mm (3.15” x 9.45”) |
| Resolution |
12 dots/mm (305dpi |
|
| Media Characteristics |
| Label Length |
L: 16 ~ 237mm (0.63” ~ 9.33”), With backing paper: 19 ~ 240mm (0.75” ~ 9.45”) |
| Media Core Diameter |
Paper core inner core diameter: ?76.4mm (3”), ?102mm (4”) |
| Media Roll Diameter |
Max external diameter: ?250mm (10”) |
| Media Sensor |
-mark sensor (Reflective type), Label Gap sensor (Can be used for center hole sensor, transmissive type), Side hole sensor, Notch sensor (Edge detection), Jump hole sensor |
| Media Thickness |
140 to 265?m (0.14 to 0.265mm) |
| Media Width |
: 22 ~ 80mm (0.87” ~ 3.15”), With backing paper: 25 ~ 83mm (0.98” ~ 3.27”) |
|
| Ribbon Characteristics |
| Ribbon Length |
Max 450mm roll |
| Ribbon Width |
84mm maximum |
|
| Performance Characteristics |
| Interface |
Plug-in interface card: USB/ LAN/ WLAN/ Parallel/ RS-232C. Standard: External port, Serial port for keypad |
| Memory |
Flash Rom : 8MB |
| Processor |
32 Bits RISC-CPU 100MHz |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:UPC-A/ UPC-E, EAN8/13, CODE39, CODE93, CODE128 GS1-128 (UCC/EA/N128), CODABAR(NW-7), Short CODARBAR(NW-7), ITF, INDUSTRIAL 2of5, MATRIX 2of5, BOOKLAND, MSI, POSTNET, GS1 DATABAR (RSS), GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Stacked, GS1 DataBar Stacked Omni-Directional, GS1 DataBar Limited, GS1 DataBar Expanded,GS1 DataBar Expanded Stacked |
|
2D:PDF417 (Ver2.4), MAXI code (Ver3.0), QR Code (Ver 8.1 including Micro QR), GS1 Data Matrix (ECC200) |
| Character Sets |
Alpha-numerical, Symbol: XU (5×9 dot), XS (17×17 dot), XM (24×24 dot), XB(48×48 dot), XL (48×48 dot), OCR-A |
| Character Size |
CG Times (Alphanumeric, symbols), CG Triumvarite (Alphanumeric, symbols) |
| Enlargement & Rotation |
Character: 0º, 90º, 180º, 270º rotation per data is available |
|
| Environment Characteristics |
| Operating Environment |
5 ~ 40ºC / 30 ~ 80% RH (without condensation) |
| Storage Environment |
-5 ~ 60ºC / 30 ~ 90% RH (without condensation) |
| User Options |
Large stacker, Label rewinder, Ribbon core adapter kit, Keypad |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
(WxDxH): 284mm x 552mm x 300mm |
| Power Requirements |
Input Voltage: AC100V ~ 240V +/- 10%, Rated Input Voltage: AC100V /AC230V |
| Weight |
16.2kg (35.71 lbs) |
|
| Options |
| Regulatory Approvals |
USA/Canada: FCC15B ClassB, UL60950-1(2001), CSA22.2 No. 60950-1-03 Europe: RoHS, CE (EN55022,EN55024), IEC/EN60950-1, China: CCC, Korea: KCC |
