| Printing Characteristics |
| Print Method |
Thermal Transfer and Direct Thermal printing |
| Print Speed |
Up to 4″/sec(101.6mm/sec) |
| Print Width |
105.7mm (4.16″) |
| Resolution |
11.8 dots/mm (300dpi) |
|
| Media Characteristics |
| Label Length |
13.0 to 997.0mm – batch 23.4 to 997.0mm – strip31.0 to 993.0mm – cut |
| Media Roll Diameter |
MAX. 150mm |
| Media Thickness |
0.1 to 0.17mm |
| Media Width |
47 to 114mm |
|
| Ribbon Characteristics |
| Ribbon Length |
300m |
| Ribbon Width |
60 to 114mm |
|
| Performance Characteristics |
| Interface |
RS 232C, optional keyboard interfaceCentronics interface(QP standardQQ option |
| Memory |
Flash ROM QP:2MB including expansionmemory boardQQ: 1MB as standard |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:UPC/EAN/JAN, Code 39,Code 93, Code 128,NW-7, ITF, MSI, EAN128,POSTNET, RM4SCC,KIXCODE |
|
2D:Data Matrix, PDF-417,symbologies: MaxicodeQR code |
| Character Sets |
Alphanumerics, symbols,and special characters |
| Character Size |
20 fonts (including EUROcharacter) Times Roman,Helvetica, Courier,Presentation, Letter Gothic,Prestige Elite |
| Enlargement & Rotation |
0°, 90°, 180°, 270° |
| Graphics |
BMP, PCX files are available |
|
| Environment Characteristics |
| Operating Environment |
5 to 40°C |
| Storage Environment |
25 – 85% Non condensing relative humidity |
| User Options |
B-7204-QM: Cutter moduleB-7904-H-QM: Strip moduleB-7704-C-QM: Centronics interface boardfor QQ model (QP standard)B-7704-IO-QM: Expansion I/O interface boardB-7804-E1M-QM: Expansion memory board(with 1MB Flash ROM) forQQ model (QP standard)KB-80-QM: External stand alonekeyboard |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
245mm270mm200mm (410mm withsupply holder unit) |
| Power Requirements |
QP: 220-240VAC,QQ: 100-120VAC |
| Weight |
4.7Kg (without paper and ribbon) |
