| Media Characteristics |
| Media Roll Diameter |
Max. Roll Size: 8”/203 mm O.D. on a 3”/76 mm I.D. core |
| Media Thickness |
Thickness (label & liner): .003”/.076 mm to .012”/.305 mm |
| Media Type |
Media Types: Continuous fanfold, die-cut or black mark |
|
| Ribbon Characteristics |
| Ribbon Length |
Standard Lengths: 1,476’/450 m or 984’/300 m; provides 3:1 & 2:1 media roll to ribbon ratios |
| Ribbon Roll Diameter |
Max. Roll Size: 3.2”/81.3 mm O.D. on a 1”/25.4 mm I.D. core |
| Ribbon Type |
Ribbon is recommended to be at least as wide as media. |
| Ribbon Setup |
Ribbon wound ink side out |
|
| Performance Characteristics |
| Software |
ZebraDesigner™ Pro |
|
ZebraDesigner |
|
ZebraDesigner for XML |
|
ZebraNet™ Utilities v 7.0 |
|
ZebraNet Bridge Enterprise |
|
Zebra Enterprise Connector |
|
ZPL® or ZPL II® programming language—selectable through software or front panel |
|
XML-Enabled printing—direct-connect integration for barcode label printing; eliminates license fees and print server hardware and lowers customization and programming costs |
|
ZBI 2.1™— Allows printers to run applications, prompt users through control-panel commands and use files stored on the printer as a data source. |
| Networking |
ZebraNet Wireless Plus Print Server |
|
ZebraNet 10/100 Print Server |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
Linear Barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case C Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2 or 5 digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5,Interleaved 2-of-5, Logmars, MSI, Codabar, Planet Code |
|
2-Dimensional: Codablock, PDF417, Code 49, Data Matrix, MaxiCode, QR Code, MicroPDF417, TLC 39, GS1 DataBar (RSS), Aztec |
| Graphic Features |
Supports user-defined fonts and graphics—including custom logos |
| Fonts and character sets |
Unicode™-compliant Global Printing |
|
Bitmap fonts A through H and GS symbols are expandable up to 10 times; height and width independent |
|
Smooth, scalable font Ø (CG Triumvirate™ Bold Condensed) is expandable dot-by-dot; height and width independent |
|
IBM® Code Page 850 International |
|
CharactersContains UFST® from Montotype Imaging, Inc. |
|
| Environment Characteristics |
| Operating Humidity |
20-85% non-condensing |
| Storage Humidity |
5-85% non-condensing |
| Operating Temperature |
40° F/5° C to 105° F/40° C (Thermal Transfer) |
|
32° F/0° C to 105° F/40° C (Direct Thermal) |
| Storage/Transport Environ |
-40° F/-40° C to 140° F/60° C |
|
| Physical Characteristics |
| Electrical |
Universal power supply with power-factor correction 90-264 VAC; 48-62 Hz |
|
Serial RS-232 and bi-directional parallel ports— with auto detect |
|
USB 2.0 port |
|
| Options |
| Regulatory Approvals |
IEC 60950-1, EN 55022 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3 |
| User Options |
For optimum print quality and printer performance, use genuine Zebra™ supplies. |
|
For optimal printing quality and proper printer performance across our product line, Zebra strongly recommends the use of genuine Zebra™ supplies as part of the total solution. Specifically, the Xi4 printer is designed to work only with genuine Zebra™ printheads, thus maximizing safety and print quality |
| Optionals and Accessories |
Rewind |
|
Cutter and catch tray |
|
Bi-fold media door with clear panel |
|
Media supply spindle for 3”/76 mm core or 40 mm core |
|
Applicator interface |
|
64 MB On-Board Linear Flash Memory |
|
Scalable and international fonts |
