| Printing Characteristics |
| Print Length |
6 ~ 1,000mm |
| Print Method |
Thermal Transfer, Direct Thermal |
| Print Speed |
SLP-T400: Up to 6 ips (152 mm/s) /SLP-T403: Up to 4 ips (100 mm/s) |
| Print Width |
SLP-T400: Up to 104 mm / SLP-T403: Up to 105.7 mm |
| Resolution |
SLP-T400: 203 dpi / SLP-T403: 300 dpi |
|
| Media Characteristics |
| Media Roll Diameter |
Up to 130 mm |
| Media Sensor |
Transmissive, Reflective (adjustable), Ribbon-End, Head open |
| Media Thickness |
0.06 ~ 0.20 mm |
| Media Type |
Gap, Black Mark, Notch, Continuous, Fan-Fold |
| Media Width |
15 ~ 116 mm |
| Supply Method |
Easy Paper Loading |
|
| Ribbon Characteristics |
| Ribbon Length |
Up to 300 m |
| Ribbon Type |
Wax, Wax / Resin, Resin |
| Ribbon Width |
33 ~ 110 mm |
| Core Inner Diameter |
12.5 / 25.4 mm |
|
| Performance Characteristics |
| Interface |
Triple Interface Standard: Serial+Parallel+USB V1.1 FSOptional: Serial+Ethernet+USB V1.1 FS |
| Memory |
8MB SDRAM, 2MB FlashROM |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D: Coda Bar, Code 39, Code 93, Code 128, EAN-8,EAN-13, IMB, Interleaved 2-of-5, ITF, UCC/EAN-128, UPC-A, UPC-E |
|
2D: Data Matrix, MaxiCode, PDF417, QR Code(select two only |
| Character Sets |
10 SLCS Resident Bitmap Fonts One SLCS Resident Scalable Font 23 Code Page |
| Graphics |
Supporting user-defined fonts, graphics, formats, and logos |
|
| Software |
| Driver / Utility |
Windows Driver, Linux CUPS Driver, Mac Driver, Virtual COMUSB/Ethernet Driver, Utility Program, Label Artist™ |
| Emulation |
SLCS, BPL-Z™, BPL-E™ |
| SDK |
Android SDK |
|
| Environment Characteristics |
| Humidity |
10 ~ 80% RH / Storage: 10 ~ 90% RH |
| Operating Environment |
5 ~ 40 °C (41 ~ 104 °F) / |
| Storage Environment |
Storage: -20 ~ 60 °C (-4 ~ 140 °F) |
| User Options |
Ethernet, RFID (Frequency: 885 ~ 955 MHz, Transmit Power: 1W,Modulation: ASK, Air Protocol: GEN2, Type: FHSS), Peeler, Auto Cutter,External Paper Supply |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
214 x 310 x 200 mm (8.42 x 12.20 x 7.87 inch) |
| Power Requirements |
EnergyStar Certified, External Power Adaptor 100-240V AC, 50/60Hz |
| Weight |
2.75 kg (6.06 lbs.) |
