| Scanning Characteristics |
| Depth Of Field |
5 mils: 1.9 to 5.0 cm / 0.75 to 2.0 in,10 mils (PDF): 3.1 to 15.2 cm / 1.25 to 6.0 in,13 mils (UPC): 0 to 20.3 cm / 0 to 8.0 in. |
| Print Contrast |
(Minimum) 25% |
| Read Rate |
(Maximum) 1,170 digital scan lines/sec.Scan Lines Digital: 104 |
| Reading Angle |
Pitch: +/- 65°; Roll (Tilt): 0 – 360°; Skew (Yaw): +/- 75° |
| Scan Resolution |
(Maximum) 0.130 mm / 5 mils |
|
| Performance Characteristics |
| Image Capture |
752 x 480 pixels; Graphic Formats: JPEG |
| Interface |
IBM 46xx; Keyboard Wedge; OEM (IBM) USB; RS-232; RS-485;USB; Wand |
| Reading Indicators (Beeper Operation) |
(Adjustable Tone and Volume); Good Read LED |
|
| Data Capture Characteristics |
| Decoding Capability |
2D Codes : Data Matrix |
|
1D / Linear Codes :Autodiscriminates all standard 1D codes including GS1Databar™ linear codes |
|
Stacked Codes :GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1DataBar Stacked Omnidirectional; PDF417 |
|
| Power Specifications |
| Current Consumption |
Operating (Typical): < 450 mAStandby/Idle (Typical): < 350 mA |
| Input Voltage |
5.0 VDC Model +/- 10% ; 8.0 – 14.0 VDC Model |
|
| Environment Characteristics |
| Ambient Light Levels |
Indoor: 40 to 6,000 lux; Outdoor: 40 to 86,100 lux |
| Drop Specification |
Drop Resistance Withstands repeated drops from 1.2 m / 4.0 ft onto a concretesurface |
| EAS Support |
Checkpoint Systems: Integrated EAS hardware will work withCounterpoint IX and Evolve D11 models |
| Electrostatic Discharge (ESD Protection ) |
(Air Discharge) 25 kV |
| Environment Sealing |
Particulate and Water Sealing IP52 |
| Humidity |
(Non-Condensing) 5 – 95% |
| Operating Temperature |
Temperature Operating: 0 to 40 °C / 32 to 104 °F |
| Storage Temperature |
Storage/Transport: -40 to 70 °C / -40 to 158 °F |
|
| Physical Characteristics |
| Dimensions |
Scanner in Stand: 18.0 x 8.1 x 9.7 cm / 7.1 x 3.2 x 3.8 in |
| Weight |
445.1 g / 15.7 oz |
| Color |
Black; Grey; Other colors and custom logo options are availablefor minimum quantity purchase. |
|
| Options |
| Regulatory Approvals |
The product meets necessary safety and regulatory approvalsfor its intended use.The Quick Reference Guide for this product can be referred tofor a complete list of certifications. |
| Safety Standards |
Environmental Compliance Complies to EU RoHSLED Classification IEC 60825 Class 1 LED |
| User Options |
Utilities:OPOS / JavaPOS JavaPOS Utilities are available for download at no chargeOPOS Utilities are available for download at no charge |
