| Scanning Characteristics |
| Depth Of Field |
Read Height 15.2 cm / 6.0 in |
| Read Rate |
(Maximum) 3,900 lines/sec,Scan Lines 52,Sides Read 5 Sides. |
| Scan Angle |
Scan Zone 360° |
|
| Performance Characteristics |
| Indicators |
Good Read LED |
| Interface |
Auxiliary Ports :EAS Port: Powered RS-232; Remote Scale Display; Scale Host |
|
Interfaces :IBM 46xx; Keyboard Wedge: Scanner Only; OEM (IBM) USB; RS-232;USB: Scanner Only |
| Motor Speed |
Motor Speed 4,500 rpm |
| Reading Indicators (Beeper Operation) |
Adjustable Tone and Volume |
|
| Data Capture Characteristics |
| Decoding Capability |
1D / Linear Codes:Autodiscriminates all standard 1D codes including GS1Databar™ linear codes. |
|
Stacked Codes :GS1 DataBar Expanded Stacked; GS1 DataBar Stacked;GS1 DataBar Stacked Omnidirectional |
|
| Power Specifications |
| AC Power Requirements |
AC Input: 100-250 VAC, 50-60 HzPower Consumption: Operating (Maximum): 8 WattsOperating (Nominal): 7 WattsSleep Mode: 4 Watts |
|
| Environment Characteristics |
| Electrostatic Discharge (ESD Protection ) |
25 kV |
| Humidity |
Humidity (Non-Condensing) 5 – 95% |
| Operating Temperature |
Temperature Operating: 10 to 40 °C / 50 to 104 °F |
| Optional Features |
All -Weighs Scale Platter :Integrated Produce Lift Bar; Produce Rail™EAS Features :Checkpoint Systems: Integrated EAS hardware will work withCounterpoint IX and Evolve D11 modelsSensormatic: Good Read AcknowledgementValue Added Features :Diagnostic Reporting; Host Download |
| Storage Temperature |
Storage/Transport: -40 to 70 °C / -40 to 158 °F |
|
| Physical Characteristics |
| Dimensions |
Depth (Below Counter): 10.2 cm / 4.0 inHeight (Above Counter): 13.0 cm / 5.1 inLength: Model 8301 (Short, Scanner Only): 35.6 cm / 14.0 inModel 8302 (Medium, Scanner Only): 40.1 cm / 15.8 inModel 8303 (Long, Scanner Only): 50.8 cm / 20.0 inModel 8304 (Medium, Scanner/Scale): 40.1 cm / 15.8 inModel 8305 (Long, Scanner/Scale): 50.8 cm / 20.0 inWidth: 29.2 cm / 11.5 in |
| Scale Capacities |
Adjustments Required: Calibration OnlyCapacity: 15.0 kg / 30.0 lbMaximum Static Weight: 68.0 kg / 150.0 lbMinimum Increment: 0.005 kg / 0.010 lbVibration Immunity: 4 Programmable Filter Settings |
|
| Options |
| Agency Approvals |
The product meets necessary safety and regulatory approvalsfor its intended use.The Quick Reference Guide for this product can be referred tofor a complete list of certifications. |
| Safety Standards |
Environmental Compl iance Complies to EU RoHSLaser Classification :Caution Laser Radiation – Do not stare into beam; CDRH ClassIIa; EN 60825 Class 1; IEC 60825 Class 1 |
| User Options |
UtilitiesOPOS / JavaPOS JavaPOS Utilities are available for download at no chargeOPOS Utilities are available for download at no charge |
