| Scanning Characteristics |
| Depth Of Field |
GD4400 Standard Range (SR)/ GD4400 High Density (HD):-Code 39: 5 mils: 4.0 to 19.0 cm / 1.6 to 7.5 in Code 39: 3 mils: 2.4 to 9.1 cm / 0.9 to 3.6 in,Data Matrix: 10 mils: 2.0 to 16.0 cm / 0.8 to 6.3 in Data Matrix: 5 mils: 2.8 to 6.1 cm / 1.1 to 2.4 in,EAN -13: 13 mils: 1.5 to 40.0 cm / 0.6 to 15.7 in PDF417: 4 mils: 1.8 to 6.8 cm / 0.7 to 2.7 in,PDF417: 10 mils: 0.5 to 22.0 cm / 0.2 to 8.6 in PDF417: 10 mils: 0 to 14.3 cm / 0 to 5.6 in,QR Code: 10 mils: 3.0 to 12.5 cm / 1.2 to 4.9 in QR Code: 6.7 mils: 2.1 to 4.2 cm / 0.8 to 1.7 in. |
| Motion Tolerance |
25 IPS |
| Print Contrast |
(Minimum) 25% |
| Reading Angle |
Pitch: +/- 40°; Roll (Tilt): 180°; Skew (Yaw): +/- 40° |
| Scan Resolution(Maximum) |
High Density (HD): 1D Linear: 0.077 mm / 3 mils; |
|
Standard Range (SR): 1D Linear: 0.102 mm / 4 mils; |
|
Data Matrix: 0.127 mm / 5 mils; PDF417: 0.102 mm / 4 mils |
|
Data Matrix: 0.178 mm / 7 mils; PDF417: 0.102 mm / 4 mils |
|
| Performance Characteristics |
| Image Capture |
Graphic Formats: BMP, JPEG, TIFF; Greyscale: 256, 16, 2 |
| Imager Sensor |
Wide VGA: 752 x 480 pixels |
| Interface |
GD4410: RS-232 / IBM 46XX / USB Multi-InterfaceGD4430: RS-232 / USB / Keyboard Wedge / Wand Multi-Interface |
| Light Source |
Aiming: 650 nm VLD |
| Reading Indicators (Beeper Operation) |
(Adjustable Tone); Datalogic ‘Green Spot’ Good ReadFeedback; Good Read LED |
|
| Data Capture Characteristics |
| Decoding Capability |
2D Codes :Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; MicroQR Code; QR Code |
|
1D / Linear Codes: Autodiscriminates all standard 1D codes including GS1DataBar™ linear codes. |
|
Postal Codes :Australian Post; British Post; China Post; IMB; Japanese Post;KIX Post; Korea Post; Planet Code; Postnet; Royal Mail Code(RM4SCC) |
|
Stacked Codes :EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBarExpanded Stacked; GS1 DataBar Stacked; GS1 DataBar StackedOmnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/EComposites |
|
| Power Specifications |
| Current Consumption |
Operating (Typical): GD4410: < 170 mA @ 5 VDC; GD4430 <160 mA @ 5 VDCStandby/Idle (Typical): 65 mA @ 5 VDC |
| Input Voltage |
GD4410: 4.0 – 14.0 VDC; GD4430: 4.2 – 5.25 VDC |
|
| Environment Characteristics |
| Ambient Light Levels |
0 – 100,000 lux |
| Drop Specification |
Drop Resistance Withstands repeated drops from 1.8 m / 5.9 ft onto a concretesurface. |
| Electrostatic Discharge (ESD Protection ) |
(Air Discharge) 16 kV |
| Environment Sealing |
Particulate and Water Sealing IP52 |
| Humidity |
Humidity (Non-Condensing) 5 – 95% |
| Operating Temperature |
Temperature Operating: 0 to 50 °C / 32 to 122 °F |
| Storage Temperature |
Storage/Transport: -20 to 70 °C / -4 to 158 °F |
|
| Physical Characteristics |
| Dimensions |
18.1 x 7.1 x 10.0 cm / 7.1 x 2.8 x 3.9 in |
| Weight |
195.0 g / 6.9 oz |
| Color |
Black; White |
|
| Options |
| Accessories |
Mounts/Stands11-0360 Holder, Multi-Purpose, Black11-0362 Holder, Multi-Purpose, GreyHLD-G040-BK Desk/Wall Holder, G040, BlackHLD-G040-WH Desk/Wall Holder, G040, WhiteSTD-AUTO-G040-BK Smart Stand, G040, BlackSTD-AUTO-G040-WH Smart Stand, G040, WhiteSTD-G040-BK Basic Stand, G040, DarkSTD-G040-WH Basic Stand, G040, White |
| Regulatory Approvals |
The product meets necessary safety and regulatory approvalsfor its intended use.The Quick Reference Guide for this product can be referred tofor a complete list of certifications. |
| Safety Standards |
Environmental Compliance Complies to China RoHS; Complies to EU RoHSLaser Classification Caution Laser Radiation – Do not stare into beam; IEC 60825Class 2 |
| User Options |
Utilities :Datalogic Aladd in™ Datalogic Aladdin configuration program is available fordownload at no charge.OPOS / JavaPOS JavaPOS Utilities are available for download at no charge.OPOS Utilities are available for download at no charge.Remote Host Download Lowers service costs and improves operations: GD4410 |
