| Scanning Characteristics |
| Depth Of Field |
PS 7000 2D High Density:-5 mils: 6.6 to 8.1 cm / 2.6 to 4.2 in,6.6 mils PDF: 4.5 to 12.7 cm / 1.8 to 5.0 in,8.3 mils: 2.5 to 20.0 cm / 1.0 to 7.9 in,8.3 mils Data Matrix: 6.1 to 11.9 cm / 2.4 to 4.7 in,10 mils PDF: 3.0 to 16.7 cm / 1.2 to 6.6 in,13 mils: 2.5 to 20.0 cm / 1.0 to 7.9 in. |
|
PS 7000 2D Standard:-6.6 mils PDF: 4.5 to 12.7 cm / 1.8 to 5.0 in,8.3 mils: 6.3 to 16.7 cm / 2.5 to 6.6 in,8.3 mils Data Matrix: 6.1 to 11.9 cm / 2.4 to 4.7 in,10 mils PDF: 3.0 to 16.7 cm / 1.2 to 6.6 in,13 mils: 2.8 to 31.0 cm / 1.1 to 12.2 in,15 mils Data Matrix: 3.3 to 23.3 cm / 1.3 to 9.2 in,35 mils Maxi Code: 2.5 to 30.5 cm / 1.0 to 12.0 in. |
| Print Contrast Ratio |
(Minimum) 37% |
| Reading Angle |
Pitch: +/- 40°; Roll (Tilt): 360°; Skew (Yaw): +/- 40° |
| Scan Resolution |
(Maximum) 0.130 mm / 5 mils |
|
| Performance Characteristics |
| Aiming Source |
Light Source Aiming: Green LED 526 nm +/- 30 nm |
| Image Capture |
Graphic Formats: BMP, JPEG, TIFF; Greyscale: 256, 16, 2 |
| Imager Sensor |
Imager Sensor VGA Plus: 752 x 480 pixels |
| Interface |
Keyboard Wedge; RS-232; USB |
| Light Source |
Illumination: Red LED 626 nm +/- 30 nm |
| Reading Indicators |
(Adjustable Tone); Good Read LED |
|
| Data Capture Characteristics |
| Decoding Capability |
2D Codes :Aztec Code; Aztec Mesas; Data Matrix; MaxiCode; QR CodeOCR Codes OCR-A; OCR-B |
|
1D / Linear Codes :Autodiscriminates all standard 1D codes including GS1DataBar™ linear codes. |
|
Postal Codes :British Post; Canadian Post; China Post; Japanese Post;KIX Post; Planet Code; Postnet |
|
Stacked Codes :Code 49; GS1 DataBar Composites; GS1 DataBar ExpandedStacked; GS1 DataBar Stacked; GS1 DataBar StackedOmnidirectional; MicroPDF417; PDF417 |
|
| Power Specifications |
| Current Consumption |
Operating (Typical): With Aiming: 700 mA @ 5 VDC; WithoutAiming: 470 mA @ 5 VDCStandby/Idle (Typical): Low Power Mode: 55 mA @ 5 VDC;Normal: 100 mA @ 5 VDC |
| Input Voltage |
4 – 14 VDC |
|
| Environment Characteristics |
| Ambient Light |
0 – 100,000 lux |
| Drop Specification |
Drop Resistance Withstands 50 drops from 2 m / 6.6 ft onto a concrete surface |
| Electrostatic Discharge (ESD Protection ) |
(Air Discharge) 25 kV |
| Environment Sealing |
Particulate and Water Sealing IP65 |
| Humidity |
(Non-Condensing) 5 – 95% |
| Operating Temperature |
Temperature Operating: -30 to 50 °C / -22 to 122 °F |
| Storage Temperature |
Storage/Transport: -40 to 60 °C / -40 to 140 °F |
|
| Physical Characteristics |
| Dimensions |
19.0 x 7.5 x 11.5 cm / 7.5 x 3.0 x 4.5 in |
| Weight |
283.0 g / 10.0 oz |
| Color |
Yellow/Black |
|
| Options |
| Accessories |
Mounts/Stands11-0110 Hands Free Stand11-0111 Universal Mounting Kit for PowerScan7-0404 Industrial Take Up ReelCases/Holsters11-0138 Heated Holder, 36 V11-0139 Heated Holder, 24 V11-0140 Heated Holder, 48 V |
| Regulatory Approvals |
Agency Approvals The product meets necessary safety and regulatory approvalsfor its intended use.The Quick Reference Guide for this product can be referred to for a complete list of certifications. |
| Safety Standards |
Environmental Compliance : Complies to China RoHS; Complies to EU RoHS |
