| Printing Characteristics |
| Print Length |
0.25″- 99″(6.35 – 2514.6 mm) |
| Print Method |
Direct thermal Optional thermal transfer |
| Print Speed |
10 IPS (254 mm/s) |
| Print Width |
4.16″ (105.7 mm) |
| Resolution |
300 DPI (12 dots/mm) |
|
| Media Characteristics |
| Media Core Diameter |
38.1mm – 76.2mm) core |
| Media Sensor |
See through” for liner-backed die-cut labelsand tags |
| Media Thickness |
0.0025″ – 0.01″ (0.0635mm – 0.254mm) |
| Media Type |
Roll-fed: 8.0″ (203.2mm) O.D. on a 1.5″- 3.0 |
| Media Width |
1.0″ – 4.65″ (25.4mm – 118.1mm) |
|
| Ribbon Characteristics |
| Ribbon Length |
Length: 1968′ (600m) |
| Ribbon Type |
Coated side in and coated side out |
| Ribbon Width |
Width range: 1.0″- 4.5″ (25.4mm – 114.3mm) |
| Core Inner Diameter |
Core: 1.0″ (25.4mm) |
|
| Performance Characteristics |
| Memory |
32MB / 64MB |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:Linear: Code 3 of 9, UPC-A, UPC-E,Interleaved 2 of 5, Industrial 2 of 5, Std 2 of 5,Code 11, Code 93, Code 128, EAN-8,EAN-13, HIBC, Codabar, Plessey, UPC 2 and5 digit addendums, Postnet, UCC/EAN Code128, Telepen, Planetcode, FIM, USPS-4 State |
|
2D :Symbologies: MaxiCode, PDF417, USD-8,Datamatrix, QR Code, Codeablock, Code 16k,Aztec, TLC 39, Micro PDF417, GS1 Databar |
| Character Sets |
Over 50 resident character sets;Unicode/UTF8 support |
| Character Size |
NETira CT – Complete printer set up utility» NETira LD – Label design software» Embedded Network web pages |
| Enlargement & Rotation |
All fonts expandable vertically and horizontallyup to 24x; fonts and graphics can be printedin four directions: 0°, 90°, 180° and 270°s |
| Graphics |
PCX, .BMP and .IMG files |
|
| Software |
| SDK |
Windows Drivers – NT, XP, Vista |
|
| Environment Characteristics |
| Factory Options |
ILPC (Hangul, Simplified Chinese, and Kanji)Ethernet-Wired, W-LAN 802.11 a/b/g withWPA2 security protocol 2 USB Host, SDIOEthernet wired LAN 10/100GPIO applicator interface card |
| Operation Environment |
32°F to 104°F (0°C to 40°C) |
| User Options |
Thermal transferInternal rewindCast peel present and internal rewindCutter (10 mil) |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
12.7″ H x 12.62″ W x 18.6″ D(322.6mm H x 320.5mm W x 472.4mm D) |
| Power Source |
Auto-sensing 90-132 or 180-264 VAC @47-63Hz |
| Weight |
45 lbs. (20.5kg) |
