| Printing Characteristics |
| Print Length |
Max 100”(2540mm) Min 0.2” (5mm) |
| Print Method |
Direct Thermal / Thermal Transfer |
| Print Speed |
2~6 ips(51~152mm/s) |
| Print Width |
Max 4.09”(104mm) |
| Resolution |
203 dpi(8 dots/mm) |
|
| Media Characteristics |
| Media Core Diameter |
Max roll capacity(OD):7”(177.8mm) Core size:1.5”(38mm) |
| Media Roll Diameter |
Max roll capacity(OD):8”(203mm) Core size:3”(76mm) |
| Media Sensor |
Media gap & black line Reflective sensor x 1 (Movable)& Transmissive sensor x 1 (Movable)/ Head open switch / Ribbon end sensor |
| Media Thickness |
Thickness:0.0025”~0.01”(0.0635~0.254mm) |
| Media Type |
Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper and fabric label |
| Media Width |
Max Width:4.4”(112mm)Min Width:1”(25.4mm) |
|
| Ribbon Characteristics |
| Ribbon Length |
Ribbon Length: max 360m wax, 300m resin |
| Ribbon Roll Diameter |
Ribbon roll – max OD: 3”(76mm) |
| Ribbon Type |
Wax, Wax/Resin, Resin (Ribbon wound ink-side in or ink-side out available) |
| Ribbon Width |
Ribbon Width: 1”~4 |
| Core Inner Diameter |
Core size – ID: 1”(25.4mm) with notch |
|
| Performance Characteristics |
| Display |
Multilingual Back-lit LCD Display 16 x 2-line, |
| Indicators |
LED indicator (Ready/Media/Ribbon)x 3 |
| Interface |
Operation Interface: Button (Feed(Config.)/Pause(Calibr.)/Cancel(Reset)) x 3 Communication Interface:X-2300/X-3200: Centronics Parallel, RS-232 serial (Baud rate:2400~115200 bps), USB, PS/2 keyboardX-2300E/X-3200E: Centronics Parallel, RS-232 serial (Baud rate:2400~115200 bps), USB, PS/2 keyboard, Ethernet |
| Memory |
16 MB DRAM (13MB User Available)8MB Flash ROM (6MB User Available) |
| Processor/CPU Type |
32 bit RISC microprocessor |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D :PPLA: Code 39, UPC-A, UPC-E, Code 128 subset A/B/C, EAN-13, EAN-8, HBIC, Codabar, Plessey, UPC2, UPC5, Code 93, Postnet, UCC/EAN-128UCC/EAN-128 K-MART, UCC/EAN-128 Random Weight, Telepen, FIM, Interleave 2 of 5 (Standard/with modulo 10 checksum/with human readablecheck digit/with modulo 10 checksum & shipping bearer bars), GS1 Data bar (RSS)PPLB: Code 39 Std. & Extended, UPC-A, UPC-E, UPC-Interleaved 2 of 5, Code 39 with check sum digit, Code 93, EAN-13,EAN-8 (Standard, 2 /5digit add-on), Codabar, Postnet, Code128 subset A/B/C, Code 128 UCC (shipping container code), Code 128 autoUCC/EAN code 128 (GS1-128), Interleave 2 of 5, Interleaved 2 of 5 with check sum, Interleaved 2 of 5 with human readable check digit, German PostcodeMatrix 2 of 5, UPC Interleaved 2 of 5, EAN-13 2/5 digit add-on, UPCA 2/5 digit add-on, UPCE 2/5 digit add-on, GS1 Data bar (RSS)PPLZ: Code39, UPC-A, UPC-E, Postnet, Code128 subset A/B/C, Interleave 2 of 5, Interleaved 2 of 5 with check sum,Interleaved 2 of 5 with human readable check digit, Code 93, Code |
|
2D:PPLA/PPLZ: MaxiCode, PDF417, Data Matrix (ECC 200 only), QR code, Composite Codes, Aztec BarcodePPLB: MaxiCode, PDF417, Data Matrix (ECC 200 only), QR code, Composite Codes, Aztec Barcode |
| Character Sets |
Internal character sets standard |
| Character Size |
5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) |
| Enlargement & Rotation |
Internal fonts are expandable up to 24×24 |
| Graphics |
4 direction 0° ~ 270° rotation |
|
| Software |
| Driver / Utility |
Printer Utility?Font Utility |
| Emulation |
X-2300: PPLA / PPLBX-2300: PPLA / PPLBX-2300Z: PPLZ |
| SDK |
Windows Driver (Windows XP/ Vista /7/8 ), BarTender® from Seagull Scientific |
|
| Environment Characteristics |
| Operation Environment |
Operation Temperature: 40°F~100°F (4°C~38°C), 10% ~ 90% non-condensing, |
| Storage Environment |
Storage Temperature: -4°F~122°F (-20°C~50°C) |
| User Options |
Guillotine cutter, Rotary cutter, Dispenser Kit, Rewinder, Media Stacker, ArgoKee |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
W 250mm x H 263mm x L 418mm |
| Power Source |
Internal Universal Switching Power Supply: Input voltage: 100~240VAC 50~60Hz, 5A |
| Weight |
24lbs(11kgs) |
