| Printing Characteristics |
| Print Length |
Min. 0.16″ (4 mm)**; Max. 68” (1727 mm) |
| Print Method |
Direct Thermal |
| Print Speed |
4 IPS (102 mm/s) |
| Print Width |
2.12″ (54 mm) |
| Printer Head |
EZPL, GEPL, GZPL auto switch |
| Resolution |
203 dpi (8 dot/mm) |
|
| Media Characteristics |
| Media Core Diameter |
1″ (25.4 mm), 1.5″ (38.1 mm) |
| Media Roll Diameter |
Max. 5” (127 mm) |
| Media Sensor |
Fixed transmissive sensor, central aligned Adjustable reflective sensor |
| Media Thickness |
Min. 0.0024″ (0.06 mm) – Max. 0.008″ (0.2 mm) |
| Media Type |
Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming |
| Media Width |
Min. 1″ (25.4 mm)-Max.4.64″ (118 mm) |
|
| Performance Characteristics |
| Interface |
Serial port: RS-232 (DB-9) IEEE 802.3 10/100 Base-Tx Ethernet port (RJ-45) |
| Memory |
8 MB Flash (4 MB for user storage) |
| Operation Panel |
One Tri-color LED: Power (Green, Orange and Red) Function Key: FEED |
| Processor |
32 bit RISC CPU |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:Code 39, Code 93, EAN 8 / 13 (add on 2 8.5), UPC A / E (add on 2 8.5), 1 2 of 5 8.1 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC / EAN-128 K-Mart, RandomWeight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM and GS1 DataBar |
|
2D:PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code |
| Character Sets |
6,8,10,12, 14, 18,24,30, 16×26 and OCR A 8. B |
| Character Size |
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable Bitmap fonts 8 times expandable in horizontal and vertical directions |
| Enlargement & Rotation |
90°, 180°, 270° rotatable90°, 180°, 270° rotatable, single characters 90°, 180°, 270 |
| Graphics |
Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software |
|
| Software |
| Driver / Utility |
Windows 2000, XP, Vista, 8 and Windows Server 2003 8.2008 |
|
| Environment Characteristics |
| Humidity |
30 – 85%, non-condensing10 – 90%, non-condensing |
| Operating Environment |
41 °F to 104°F [5°C to 40°C) |
| Storage Environment |
-4°F to 122°F (-20°C to 50°C) |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
8.58” (218 mm)6.53″ (166 mm)6.61″ (168 mm) |
| Power Requirements |
Auto Switching 100-240V AC, 50-60HZ |
| Weight |
3.3 lbs (1.5 Kg), excluding consumables |
|
| Options |
| Accessories |
Cutter Module Label Dispenser External Label Roll Holder for 10″ (250 mm) O.D. label rolls |
| Regulatory Approvals |
CE (EMC), FCC Class A, CB, cUL and CCC |
