| Performance Characteristics |
| Application Software |
Available on the Apple® App Store or via 3rd party application developers (visit www.isvstore.com/iosapps formore information) |
| Device Compatibility |
Apple® iPod touch® (fifth generation) |
| Encryption Supported |
DES, TDES, AES |
| I/O Ports |
Custom Mini USB |
| Interfaces |
UART between SL22 Apple® iOS device; USB/UART between SL22 & PC |
|
| Data Capture Characteristics |
| Decode Capabilities |
Reads standard 1D, PDF, 2D, Postal and OCR symbologies |
|
Number of Scans Up to 28,000 scans (1 scan per second over 8 hours) |
|
Number of Swipes Up to 28,000 swipes (1 swipe per second over 8 hours) |
| Magnetic Stripe Reader |
Integrated 3-track bidirectional MSR reader (supports encrypted and unencrypted data output)Swipe Speed : 3 to 75 inches per second |
| Scanner |
N5600 Standard range (SR) imager with green LED aimer that comes equipped with Adaptus 6.0 Imaging Technology |
|
| Power Specifications |
| Battery Life |
Expected Hours of Operation 8 hours (Captuvo SL22 + Apple® iPod touch®)Expected Charge Time 6 Hours |
| Power Supply |
Power Supply 5V, 1A wall adapter/Input Voltage 5V |
| Standard Battery |
Removable 1150mAh lithium ion battery |
|
| Environment Characteristics |
| Development Environment |
Captuvo SDK for Apple® iOS X |
| Drop Specification |
Designed to withstand 1.2 m (4´) drops to concrete, all axis under room temperature |
| Electrostatic Discharge (ESD) |
±6 KV Direct & ±10 KV Air |
| Environmental Sealing |
IP30 |
| Operating Temperature |
0°C to 35°C (32°F to 95°F) |
| Relative Humidity |
5% to 85% relative humidity, non-condensing |
| Storage Temperature |
-20°C to 45°C (4°F to 113°F) |
|
| Physical Characteristics |
| Audio |
Access to iPod touch® 3.5-mm stereo headphone minijack, speaker and microphone |
| Buttons |
Left and right side scan buttons; sleep/wake button (extension of iPod touch® button); access to iPod touch® Homebutton |
| Camera |
Access to iPod touch® front and back cameras |
| Dimensions (W x H x D) |
143.5 mm x 70.3 mm x 30 mm (5.6? x 2.8? x 1.2?) |
| Key Management Supported |
DUKPT |
| Weight |
(without iPod touch) 125g – 139g (4.4 oz – 4.9 oz) depending on configuration |
|
| Options |
| Accessories |
Standard USB A to Custom Mini USB cable (included), USB wall adapter for US, EU & UK (included), holster,protective rubber boot, wrist lanyard |
