| Performance Characteristics |
| Application Software |
Honeywell Power Tools and Demos; Microsoft® SDK; Remote MasterMind for Mobility |
| CPU/Processor |
416MHz MTK |
| Interface |
I/O Ports : USB charge/Comm Cable USB/RS232 baseCommunication : USB 2.0 high speed client |
| Memory |
Memory 256 MB RAMFlash Memory 512 MB on board FLASH memory. Supports optional Micro SD memory expansion |
| Operating System |
Microsoft® Windows® Mobile 6.5 Professional |
| Third-Party Software |
ITScriptNet™ rapid application development software with Ready To Go applications |
|
| Communication Modules |
| GPS |
Integrated assisted GPS (AGPS) |
| WLAN Radio |
802.11 b/g WAPI support |
| WLAN Security |
WEP, WPA,WPA-PSK, WPA2, WPA2-PSK |
| WPAN Radio |
Bluetooth V2.1 with EDR |
| WWAN Radio |
GSM/GPRS/EDGE voice and data |
|
| Data Capture Characteristics |
| Decode Capabilities |
Reads standard 1D symbologies, and 2D symbologies (when equipped with optional software) |
| Imager/Scanner |
Honeywell 1D scan engine |
|
| Power Specifications |
| Battery Life |
Expected Charge Time Less than 6 hours |
|
Expected Hours of Operation WLAN/high scanning profile: 8 hours; WWAN & GPS profile: 8 hours; GSM Talk Time: 6 hours; typical run timesusing system default settings |
| Standard Battery |
Li-Ion, 5.7 watt-hour |
|
| Environment Characteristics |
| Development Environment |
Honeywell SDK for Microsoft® Windows® Mobile 6.5 Professional and Visual Studio 2008 |
| Drop Specification |
3’ / 0.9m to concrete across operating temperature; 4’ / 1.2m to concrete at room temperature |
| Electrostatic Discharge (ESD) |
8KV Contact, 15 KV Air |
| Environmental Sealing |
Certified to meet IP54 standards for moisture and particle resistance |
| Operating Temperature |
14°F to 122°F (-10°C to 50°C) |
| Relative Humidity |
95% humidity, non-condensing |
| Storage Temperature |
-4°F to 140°F (-20°C to 60°C) |
| Tumble Specification |
Exceeds 800 (1m) tumbles per IEC 60068-2-32 specification |
|
| Physical Characteristics |
| Audio |
Speaker, HAC receiver, microphone, vibrator |
| Camera |
3 mega pixel/auto focus/flash LED; optional 2D bar code scanning software available |
| Dimensions (W x H x D) |
134 mm x 65 mm x 18.5 mm (5.3? x 2.6? x 0.7?) |
| Display |
2.8? QVGA transmissive |
| Keypad Options |
29-key numeric keyboard w/IMD keys |
| Storage Expansion |
User accessible Micro SDHC memory card slot. Please check current price guide for available qualified card options |
| Touch Panel |
4-wire resistive |
| Weight |
7.1 oz (200g) |
