| Performance Characteristics |
| CPU/Processor |
Marvell XScale PXA300 624 MHz |
| I/O Ports |
Full speed USB 1.1 from cradle (or I/O cable); RS232 (115 Kbps) from cradle |
| Memory |
Windows® CE 5.0: 128 MB RAM X 128 MB Flash; Windows® Embedded Handheld 6.5: 256 MB RAM X 256 MB Flash |
| Operating System |
Microsoft® Windows CE 5.0; Windows® Embedded Handheld 6.5 |
| Software |
Application Software Honeywell Powertools® and Demos |
|
Third-Party Software SOTI MobiControl (remote device management), Naurtech CETerm™ Terminal Emulation (TNVT, 3270, 5250), andITScriptNet™ (availability may be limited to choice of operating system) |
|
| Communication Modules |
| WLAN Radio |
Wi-Fi Alliance Certification, Wireless Security Supplicant (DeviceScape), 802.1x, WPA2, EAP, WEP, LEAP, TKIP,MD5, EAP-TLS, EAP-TTLS, WPA-PSK, PEAP, CCXv4 |
| WPAN Radio |
Bluetooth® Class II (10 m) v2.0 Enhanced Data Rate (EDR) with on-board antenna. BQB certified |
| WWAN Radio |
Dual Mode 802.11 b/g (11 Mbps/54 Mbps) with internal antenna |
|
| Data Capture Characteristics |
| Decode Capabilities |
Imager: Reads standard 1D and 2D symbologies. Laser: Reads standard 1D symbologies |
| Imager/Scanner |
Imager: 5100SR, 5100SF, 5100HD, 5300SR, 5300SF, and 5300HD come with Adaptus Technology and Laser Aimer;Laser: IS4813 |
|
| Power Specifications |
| Battery Life |
Expected Hours of Operation 8+ hours (with scan and continuously transmitting)*Expected Charge Time Less than 4 hours |
| Extended Battery |
Extended: Li-Ion 3.7 V, 3300 mAh (includes extended battery door) |
| Standard Battery |
Standard: Li-Ion, 3.7 V, 2200 mAh; |
|
| Environment Characteristics |
| Development Environment |
Honeywell SDK for Windows® CE 5.0; Honeywell SDK for Windows® Embedded Handheld 6.5 and Visual Studio 2008 |
| Drop Specification |
Withstands multiple 4´ (1.2 m) drops onto concrete, all axis and across operating temperature range |
| Electrostatic Discharge (ESD) |
Air: ±15 kV; Contact: ±8 kV |
| Environmental Sealing |
Independently certified to meet IP54 standards for moisture and particle resistance |
| Operating Temperature |
Imager: 14°F to 122°F (-10°C to 50°C)Laser: 14°F to 104°F (-10°C to 40°C) |
| Relative Humidity |
95% humidity, non-condensing |
| Storage Temperature |
-4°F to 158°F (-20°C to 70°C) |
| Tumble Specification |
500 3.3´ (1 m) tumbles (1,000 drops) |
|
| Physical Characteristics |
| Audio |
Built-in microphone and speaker, stereo headset jack |
| Dimensions (W x H x D) |
Standard battery: 175 mm x 69 mm x 39 mm (6.9? x 2.7? x 1.5?)Extended battery: 175 mm x 69 mm x 43 mm (6.9? x 2.7” x 1.7? ) (includes handstrap)At grip: 58 mm (2.3?) |
| Display |
2.8? transmissive active matrix 65k color LCD with backlight, QVGA (240 x 320) |
| Keypad Options |
28-key shifted alpha numeric with backlit keys |
| Storage Expansion |
User accessible Micro SDHC memory card slot. Please check current price guide for available qualified card options |
| Weight |
Imager: Standard battery: 8.7 oz (247g); Extended battery: 9.5 oz (270g);Laser: Standard battery: 8.9 oz (252g); Extended battery: 9.7 oz (275g) (includes handstrap) |
|
| Options |
| User Options |
Voice Communication Voice-over-IP and Push-to-Talk ready |
