| Performance Characteristics |
| CPU/Processor |
800MHz TI OMAP |
| HSM Application Software |
Honeywell Powertools® and Demos, Remote MasterMind™ for Mobility remote device management |
| I/O Ports |
USB 2.0 |
| Memory |
256 MB RAM X 512 MB Flash |
| Operating System |
Microsoft® Windows® Embedded Handheld 6.5 |
| Sensors |
3-Axis/2g Accelerometer |
|
| Communication Modules |
| GPS |
Integrated autonomous GPS receiver with built-in Assisted-GPS (A-GPS) services and software utilities |
| WLAN Radio |
IEEE 802.11 a/b/g/n; Wi-FiTM certified |
| WLAN Security |
WEP, 802.1x, LEAP, TKIP, MD5, EAP-TLS, EAP-TTLS, WPA-PSK, WPA v2.0, PEAP, WAPI, CCXv4 |
| WPAN Radio |
2.4 GHz (ISM Band) Adaptive Frequency Hopping Bluetooth® v2.1 + EDR; Class II: 10m (33’) line of sight |
| WWAN Radio |
GSM (Voice and Data): 3.9G–HSPA+ (800/850/1900/1700/2100 MHz), GSM/GPRS/EDGE (850/900/1800/1900 MHz)CDMA (Voice and Data): EVDO Rev A – 1xRTT/EVDO (800/1900 MHz)Software definable Gobi 3000 (Data only): 3.9G – HSPA+/UMTS (800/850/900/1700/1900/2100MHz), GSM/GPRS/EDGE (850/900/1800/1900MHz) and EVDO Rev A – 1xRTT/EVDO (800/1900 MHz) |
|
| Data Capture Characteristics |
| Decode Capabilities |
Decode Capabilities Decodes standard 1D and 2D bar code symbologies |
|
Decode Options Supports the following Adaptus 6.0 imaging scan engines: N5603-SR, N5603-ER |
|
| Power Specifications |
| Battery Life |
Standard/Extended: 6.5 hours/12 hours (decoding and sending data over WLAN every 9 seconds)Extended: 8.5 hours (decoding and sending data over WWAN every 15 seconds, GPS continuously receiving data) |
| Extended Battery |
Extended: Li-ion 3.7 V, 4000 mAh |
| Standard Battery |
Standard: Li-ion 3.7 V, 2300 mAh; |
|
| Environment Characteristics |
| Development Environment |
Honeywell SDK for Microsoft Windows Embedded Handheld 6.5 |
| Drop Specification |
Designed to withstand 5’ (1.5m) drops to concrete |
| Electrostatic Discharge (ESD) |
±15KV Air and ±8KV Contact |
| Environmental Sealing |
Independently certified to meet IP64 standards for moisture and particle intrusion |
| Operating Temperature |
-10° to 50°C (14° to 122°F) |
| Relative Humidity |
0 to 95% relative humidity (non-condensing) |
| Storage Temperature |
-20° to 70°C (-13° to 158°F) |
| Tumble Specification |
Designed to withstand up to 1,600 (1m) tumbles per IEC 60068-2-32 specification |
|
| Physical Characteristics |
| Audio |
Speaker, HAC receiver, microphone, vibrator, echo cancellation, Bluetooth® headset support |
| Camera |
3.0 mega pixel camera; autofocus; flash LED |
| Dimensions (W x H x D) |
Standard Battery: 157 mm x 76 mm x 28 mm (6.2? x 3.0? x 1.1?)Extended Battery: 157 mm x 76 mm x 33 mm (6.2? x 3.0? x 1.3?) |
| Display |
8.9 cm (3.5?) VGA color, high resolution, full axis viewing, sunlight readable display |
| Keypad Options |
Standard Keyboards: 30-key numeric and 46-key QWERTY |
| Storage Expansion |
User accessible microSD slot (SDHC compatible). Please check with your Honeywell representative for availablequalified card options |
| Touch Panel |
Industrial touch panel with 4 wire resistive touch and support for finger touch and stylus |
| Weight |
Standard Battery: 324g (11.4 oz); Extended Battery: 380 g (13.4 oz) |
