| CPU/Processor |
Marvel XScale PXA270 624 MHz |
| I/O Ports |
RS-232/USB/Charging connector, integrated IrDA port supports SIR & FIR modes |
| Memory |
256MB RAM X 1GB Flash |
| Operating System |
Windows Mobile 6.5 Professional and Classic editions |
| Third-Party Software |
SOTI MobiControl (remote device management), Naurtech CETerm and PowerNet™ Terminal Emulation (TNVT,3270, 5250), and ITScriptNet™ |
|
| Communication Modules |
| GPS |
Integrated autonomous GPS receiver with built-in Assisted-GPS (A-GPS) services and software utilities. |
| Voice Communication |
Full voice support including handset mode, headset mode (wired and wireless), and speaker phone mode viaGSM radio. Supports Voice over WLAN. |
| WLAN Radio |
IEEE 802.11a/b/g |
| WLAN Security |
Wi-Fi Certified, WPA2, EAP, CCXv4, WEP, LEAP, TKIP, MD5, EAP-TLS, EAP-TTLS, WPA-PSK, PEAP |
| WPAN Radio |
Bluetooth V2.0 + EDR |
| WWAN Radio |
3.5G GSM/UMTS/HSDPA radio with Penta-Band antenna – supports all GSM frequency bands850/900/1800/1900/2100 MHz. |
|
| Data Capture Characteristics |
| Decode Capabilities |
Reads standard 1D and 2D symbologies |
| Imager/Scanner |
5300 Standard Range (SR), Smart Focus (SF), and High Density (HD) Imagers with High-Visibility laser aimer. Allimagers equipped with Adaptus 5.5 Imaging Technology. |
|
| Power Specifications |
| Battery Life |
Expected Hours of Operation WLAN/Max scanning: 9+ hours; WAN/GPS: 8+ hours; Talk time: 6 hoursExpected Charge Time Up to 4 hours when charging completely discharged battery |
| Standard Battery |
7.4 volt high capacity, hot swap Li-ion battery pack |
|
| Environment Characteristics |
| Development Environment |
Honeywell SDK for Windows Mobile 6.5 |
| Drop Specification |
Withstands multiple 5 ft. (1.5 m) drops to concrete |
| Electrostatic Discharge (ESD) |
Air: 15 KV; Contact: 8 KV |
| Environmental Sealing |
Independently certified to meet IP64 standards for moisture and particle resistance |
| Operating Temperature |
14° to 122°F (-10°C to 50°C) |
| Relative Humidity |
95% humidity, non-condensing |
| Storage Temperature |
-4° to 158°F (-20° to 70°C) |
| Tumble Specification |
Exceeds 2000 1.6 ft. (0.5 m) tumbles |
|
| Physical Characteristics |
| Audio |
Integral Microphone, full range high output main speaker (back), Hearing Aide Compliant (HAC) receiver audiospeaker (front), mono audio and microphone input supported through the I/O connector |
| Camera |
2 megapixel camera with Automated Camera Control (ACC). Features include automated picture profiles, cameraApplication Programming Interface (API), cooperational use of camera and imager, and flashlight utility |
| Dimensions (W x H x D) |
165 mm x 85 mm x 41 mm (6.5? x 3.3? x 1.6?) |
| Display |
3.7? high-resolution VGA transflective color display with industrial touch panel |
| Keypad Options |
In-mold, hard-top keypad options: 31-key Numeric and 45-key QWERTY |
| Storage Expansion |
User accessible Micro SDHC memory card slot. Please check current price guide for available qualified card options |
| Weight |
15.6 oz. (445g) – 17.1 oz. (486g) |
