| Performance Characteristics |
| Audio Support |
Speaker, Vibrator |
| CPU/Processor |
ARM9 Core 266MHz |
| Indicator |
Blue, Green and Red |
| Interface |
USB / RS-232(4 Wires) |
| Memory |
RAM 128MB Mobile DDRAM ROM 128MB Nand Flash |
| Operating System |
WinCE 5.0 |
| Software |
embedded Visual C++ 4.0, Visual Studio.NET, Visual Studio 2005, Windows CE SDK |
|
| Data Capture Characteristics |
| Decode Capabilities |
Auto discriminates all standard one-dimension barcodes; including GS1 databar. Other symbologies can be ordered optionally (2D Symbology – UCC/EAN-Composite, Code 16K, PDF417, Micro PDF 417 for PT-6300, PT-6310 and PT-6320) |
| Depth Of Field |
600mm (code 39, 20mils, PCS 90%) |
| Resolution |
0.127mm (5mil) at PCS 90% |
| Scanner Systems |
Long Range CCD scanner 2048 pixels |
| Scanning Rate |
400 scans /sec |
|
| Power Specifications |
| Power Supply |
Power supply: DC 5V 3A AC Power 100-240V 0.5A, 50-60HZ, 33-48VA |
| Standard Battery |
1) Mobile Computer: Rechargeable 3.7V 1950mAh Li-Polymer Battery 2) Optional Pistol Grip: Rechargeable 3.7V 4400mAh Li-ion Battery |
|
| Environment Characteristics |
| Drop Specification |
1,2M/4ft (Terminal) 0.9M/3ft (Cradle)/(4 drops per 6 sides) 2) IP54 |
| Electrostatic Discharge (ESD) |
+/-15 KV air discharge 2) +/- 8 KV direct discharge |
| Humidity |
Operating: Non-condensed 10-90% 2) Storage: Non-condensed 5-95% |
| Operating Temperature |
-10°C to 60°C /14°F to 140°F |
| Storage Temperature |
-20°C to 70°C / -4°F to 158°F |
|
| Physical Characteristics |
| Dimensions (W x H x D) |
168.8mm (L) x 70.1mm (W) x 34.0mm (H) |
| Display |
2.4” LCD TFT Transmissive, 240 x 320 QVGA 65K colors with Touch panel |
| Expansion Slot |
Standard SD |
| Keypad |
29 Numeric |
| Weight |
250g (including battery) |
|
| Options |
| Accessories |
Charging & Communication cable / Charging & Communication Cradle / Pistol Grip / Four Slot Charging Base / Holster |
| Regulatory Approvals |
FCC, CE, BSMI, CCC |
