| Performance Characteristics |
| CPU/Processor |
PXA320 806 MHz |
| I/O Ports |
RS-232/USB 2.0/audio out/charging connector |
| Memory |
256MB SDRAM x 256MB Flash |
| Operating System |
Microsoft® Windows® Mobile 6.5, Microsoft® Windows® CE 6.0 |
| Optional Software |
Wavelink TE, RFTerm® (TN5250,TN3270) VT220), AppLock utility controls user application access and unwantedconfiguration changes, multiple language OS support, voice recognition, Wavelink Avalanche and LXE eXpressConfig compatible, Stay-Linked Ready |
|
| Communication Modules |
| WLAN Antennas |
Internal antenna diversity |
| WLAN Radio |
802.11 a/b/g |
| WLAN Security |
WPA, WPA2 (Personal and Enterprise), 802.11x, EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2,PEAPv1/EAP-GTC, WMM, CWG-RF Profile, CCX v.4, WAPI |
| WPAN Radio |
Bluetooth® 2.0+EDR |
|
| Data Capture Characteristics |
| Decode Capabilities |
Reads standard 1D and 2D symbologies |
| Imager/Scanner |
Standard Range Area Imager with High Visibility Aimer, Base Laser Engine, Standard Laser Engine, Multi-RangeExtended Range Engine |
|
| Power Specifications |
| Standard Battery |
Full shift battery life with typical usage 2200mAh@7.4V |
|
| Environment Characteristics |
| Development Environment |
Honeywell SDK for Windows® Embedded |
| Drop Specification |
Multiple 5 ft. (1.5m) drops to concrete (w/ handle); 6 ft. (1.8m) w/ rubber boot accessory (w/o handle) |
| Electrostatic Discharge (ESD) |
Air: ±15 KV; Contact: ±8 KV |
| Environmental Sealing |
Independently certified to meet IP65 standards for moisture and particle resistance |
| Operating Temperature |
14° to +122°F (-10° to +50°C) |
| Relative Humidity |
5 to 100% relative humidity condensing at 104°F (40°C) |
| Storage Temperature |
-4° to +158°F (-20° to +70°C) |
