| Performance Characteristics |
| CPU/Processor |
16-bit CMOS, low power consumption |
| I/O Ports |
Unit: Cradle IR, Class 2 Bluetooth (optional); Cradle: USB, RS232, Modem cradle (56k) |
| Operating System |
Program memory: 2 MB flash ROMData memory: 2 MB SRAM |
|
| Communication Modules |
| WPAN Radio |
Class 2 Bluetooth (up to 10 m) |
|
| Data Capture Characteristics |
| Decode Capabilities |
Reads standard 1D symbologies |
| Depth Of Field |
Narrow Width Depth of Field5.2 mil 70 mm – 95 mm (2.8? – 3.8?)7.5 mil 57 mm – 171 mm (2.3? – 6.8?)10.4 mil 50 mm – 210 mm (2.0? – 8.3?)13 mil 50 mm – 254 mm (2.0? – 10.0?)19.5 mil 75 mm – 300 mm (3.0? – 11.8?) |
| Imager/Scanner |
Laser Scanner Visible Laser Diode 650 nm ± 10 nm |
|
| Power Specifications |
| Backup Battery |
Back-up: 3.0 V, 7 mAh Li-ion rechargeable |
| Standard Battery |
Main: 3.7 V, 700 mAh Li-ion rechargeable; |
|
| Environment Characteristics |
| Development Environment |
Windows-based Optimizer; optional C & BASIC compilers |
| Drop Specification |
Designed to withstand 1.2 m (4´) drops |
| Operating Temperature |
0°C to 55°C (32°F to 131°F) |
| Relative Humidity |
5% to 95% relative humidity, non-condensing |
| Storage Temperature |
(-20°C to 60°C) (-4°F to 140°F) |
|
| Physical Characteristics |
| Audio |
Programmable buzzer 1 kHz – 4 kHz |
| Dimensions (W x H x D) |
Terminal: 137 mm x 55 mm x 28 mm (5.4? x 2.2? x 1.1?)Cradle: 58 mm x 92 mm x 110 mm (2.3? x 3.6? x 4.3?) |
| Display |
LCD – 100 x 64 pixels, back-lit |
| Keypad Options |
21 rubber keys; alpha/numeric, function, scanner |
| Weight |
4.9 oz (140g) including batteries |
