| Scanning Characteristics |
| Motion Tolerance |
Horizontal velocity: 5 in. (12.7 cm) per second |
| Print Contrast |
25% minimum reflectance |
| Reading Perfomance |
Paper Label / English / Metric:5 mil (Code 39) :1.1 – 6.5 in: 2.8 – 16.5 cm |
| Scan Angle |
Roll / Pitch / Yaw: DL: 360°, ±65°, ±60° |
|
| Performance Characteristics |
| Imager Field Of View |
(Vertical x Horizontal)DL: 34° V x 43° H |
| Interface |
DS6708: RS-232C (Standard, Nixdorf, ICL, and Fujitsu); USB (Standard, IBM SurePOS, Macintosh) and Synapse connectivity allows for connectivity to all of the above plus many non-standard interfaces; IBM 468x/469x and keyboard wedge |
| Light Source |
Aiming: 650 nm laser diodeIllumination: 630 nm LED |
|
| Data Capture Characteristics |
| Decoding Capability |
2-D: MaxiCode, DataMatrix (ECC 200), QR Code and Aztec |
|
1-D: UPC/EAN and with supplementals, Code 39, Code 39 Full ASCII, Tri-optic Code 39, RSS variants, Code 128, GS1DataBar (formerly UCC/EAN 128), Code 128 Full ASCII, Code 93, Codabar (NW1), Interleaved 2 of 5, Discrete 2 of 5, MSI, Codell, IATA, Bookland EAN, Code 32PDF417 (and Variants): PDF417, microPDF417 and composite codesPostal: U.S. Postnet and Planet, U.K., Japan, Australian, and Dutch |
|
| Power Specifications |
| Voltage and Current |
5 +/-10%VDC @ 350 mA |
|
| Environment Characteristics |
| Ambient Light Levels |
Ambient Light Immunity: Immune to normal artificial indoor and natural outdoor (direct sunlight) lighting. |
| Drop Specification |
Withstands multiple 6 ft. (1.8m) drops to concrete |
| Environment Sealing |
IP41 (Water and Dust Resistant) |
| Humidity |
5% to 95%, non-condensing |
| Operating Temperature |
32° to 122° F / 0° to 50° C |
| Storage Temperature |
-40° to 158° F / -40° to 70° C |
|
| Physical Characteristics |
| Dimensions |
6.55 in. H x 4.72 in. L x 2.82 in. W 16.6 cm H x 11.9 cm L x 7.1 cm W |
| Weight |
6.4 oz. (182 g) |
| Color |
Cash Register White (shown) or Twilight Black |
|
| Options |
| Accessories |
Mounting Options :Intellistand with adjustable height: 5–10 in. (12.7–25.4 cm) and adjustable angle: 0°–90° Desktop and wall-mount holders are also available.Power Supplies: Power supplies are available for applications that don’t supply power over the host cable |
| Regulatory Approvals |
Electrical Safety: UL6950-1, CSA C22.2 No. 60950-1, EN60950-1 / IEC60950-1Laser Safety: EN60825-1:1994 +A1: 2002 +A2 :2001, IEC60825-1, 21CFR1040.10 and 21CFR1040.11, CDRH Class II, IEC Class 2EMI/RFI: FCC Part 15 Class B, ICES-003 Class B, CISPR 22, CISPR 24; Medical electrical equipment: EN60601-1-2: 2002Environmental: Compliant with RoHS directive 2002/95/EEC |
