| Scanning Characteristics |
| Motion Tolerance |
Horizontal velocity: 5 in. (12.7 cm) per second |
| Print Contrast |
25% minimum reflectance |
| Reading Perfomance |
Paper Label /English / Metric:Code 39 – 3 mil/0.84” – 2.42”/2.13 – 6.15 cm |
| Scan Angle |
Roll / Pitch / Yaw1: 360°/±65°/±60° |
|
| Performance Characteristics |
| Imager Field Of View |
(Vertical x Horizontal)30° V x 40° H |
| Imaging Characteristics |
Image (Pixels): 1.3 Megapixel: 1280 pixels H x 1024 pixels VGraphics Format Support: Images can be exported as Bitmap, Jpeg, and TiffImage Transfer Speed: USB 1.1: Up to 12 Megabits/secondRS232: Up to 115 kb baud rateImage Transfer Time: Typical USB application is ~ 0.2 seconds with acompressed Jpeg of 100 kb |
| Interface |
USB and RS-232 |
| Light Source |
Aiming: 650 nm laser diodeIllumination: 630 nm LED |
|
| Data Capture Characteristics |
| Decoding Capability |
2-D: MaxiCode, DataMatrix (ECC 200), QR Code,microQR, Aztec |
|
1-D: UPC/EAN and with supplementals, Code 39,Code 39 Full ASCII, Tri-optic Code 39,GS1DataBar(formerly RSS), Code 128, Code 128 Full ASCII,GS1-128 (formerly UCC/EAN-128), Code 93,Codabar (NW1), Interleaved 2 of 5, Discrete 2 of 5,MSI, Codell, IATA, Bookland EAN, Code 32PDF417 (and Variants): PDF417 and microPDF417Postal: U.S. Postnet and Planet, U.K., Japan, Australian,Dutch, 4 State Postal, Post US4 |
|
| Power Specifications |
| Voltage and Current |
5 +/-10%VDC @ 350 mA |
|
| Environment Characteristics |
| Ambient Light Levels |
Ambient Light Immunity: Immune to normal artificial indoor and natural outdoor(direct sunlight) lighting |
| Drop Specification |
Withstands multiple 6 ft. (1.8m) drops to concrete |
| Humidity |
5% to 95%, non-condensing |
| Operating Temperature |
32° to 122° F/0° to 50° C |
| Storage Temperature |
-40° to 158° F/-40° to 70° C |
|
| Physical Characteristics |
| Dimensions |
6.55 in. H x 4.72 in. L x 2.82 in. W16.6 cm H x 11.9 cm L x 7.1 cm W |
| Weight |
6.4 oz./182 g |
| Color |
Cash Register White or Twilight Black |
|
| Options |
| Accessories |
Mounting Options Intellistand with adjustable height: 5–10 in.(12.7–25.4 cm) and adjustable angle: 0°–90°;desktop and wall-mount holders are also available.Power Supplies: Power supplies are available for applications that don’tsupply power over the host cable. |
| Regulatory Approvals |
Electrical Safety: UL6950-1, CSA C22.2 No. 60950-1,EN60950-1 / IEC60950-1Laser Safety: EN60825-1:1994 +A1: 2002 +A2 :2001, IEC60825-1,21CFR1040.10 and 21CFR1040.11, CDRH Class II,IEC Class 2EMI/RFI: FCC Part 15 Class B, ICES-003 Class B, CISPR 22, CISPR24; Medical electrical equipment: EN60601-1-2: 2002Environmental: Compliant with RoHS directive 2002/95/EEC |
