| Performance Characteristics |
| Communication Interface |
USB 1.1 Host and Client |
| CPU/Processor |
Marvell™ PXA 320 @ 806 MHz processor |
| Memory |
256 MB RAM/1 GB Flash |
| Notification |
Audible tone plus multi-color LEDs, Vibrate |
| Operating System |
Microsoft® Windows Mobile® 6.5 Classic |
|
| Communication Modules |
| WLAN Antennas |
Internal |
| WLAN Radio |
Quad-mode IEEE® 802.11a/b/g/nData Rates Supported: 802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48 and 54 Mbps802.11a: 6, 9, 12, 18, 24, 36, 48 and 54 Mbps 802.11n: MCS0 to MSC7 up to 72.2 Mbps Operating Channels: Chan 36-165 (5180 – 5825 MHz), Chan 1-13 (2412-2472MHz) |
| WLAN Security |
Legacy, WPA and WPA2WEP (40 or 104 bit), TKIP and AESTLS, TTLS (MS-CHAP), TTLS (MS-CHAP v2), TTLS(CHAP), TTLS (MD5), TTLS (PAP), PEAP-TLS, PEAP (MSCHAPv2), PEAP (EAP-GTC), EAP-FAST-TLS, EAP-FAST(MS-CHAP v2), EAP-FAST (EAP-GTC) and LEAP |
| WPAN Radio |
Bluetooth :Class II, v 2.1 Enhanced Data Rate (EDR);integrated antenna |
|
| Data Capture Characteristics |
| 1D Laser Scanner (SE960) |
Scan Rate 104 (± 12) scans/sec (bidirectional) |
|
Optical Resolution 0.005 in. minimum element width |
|
Scan Angle (typical)* Wide: (Default) 47°; Medium: 35°; Narrow: 10° |
|
Roll ± 35° from verticalPitch Angle ± 65° from normalSkew Tolerance ± 40° from normal |
|
Ambient LightImmunity :Tolerant to typical artificial indoor and natural outdoor(direct sunlight) lighting conditions. Fluorescent,Incandescent, Mercury Vapor, Sodium Vapor,LED: 450 Ft Candles (4,844 Lux) Sunlight: 10000 Ft Candles (107,640 Lux)Note: LED lighting with high AC ripple content canimpact scanning performance. |
| 2D Imager Engine (SE4500-SR AND SE4500-DL) |
Ranges:SR Focus Range : Near : Far5 mil Code 39: 2.1 in./53 mm : 7.5 in./191 mm100% UPC/EAN: 1.6 in./41 mm : 15.5 in./394 mm6.7 mil PDF417: 3.4 in./86 mm : 7.1 in./180 mmDL Focus Range: Near : Far5 mil Code 39: 1.4 in./36 mm : 7.3 in./185 mm100% UPC/EAN: 1.6 in./41 mm : 12 in./305 mm5 mil PDF417: 2.8 in./71 mm :4.5 in./114 mm |
|
Illumination Element 625 nm ± 5 nm |
|
Aiming Element (VLD) 655 nm ± 10 nm |
|
Field of View Horizontal: 40°; Vertical: 25° |
|
Sensor Resolution 752 H x 480 V pixels (gray scale) |
|
Ambient Light Total darkness to 9,000 ft. candles/96,900 lux |
|
Roll 360°Pitch Angle ± 60° from normalSkew Tolerance ± 60° from normal |
| Data Capture Specifications |
Multiple configurations available: 1D SE960 laserscanner; 2D SE4500-SR imager; 2D SE4500-DL imager;3.2 megapixel color camera option available |
|
| Power Specifications |
| Backup Battery |
Ni-MH battery (rechargeable) 18mAh 2.4V (not useraccessible) |
| Battery Performance |
User Profiles: Minimally 8 hours based on 600 scans and WLANtransmits per hour with display on and standardcapacity battery |
| Extended Battery |
Rechargeable Lithium Ion 3.7V, 3600 mAh Smart Battery |
| Standard Battery |
Rechargeable Lithium Ion 3.7V, 2400 mAh Smart Battery |
|
| Environment Characteristics |
| Clock |
Integrated real time clock |
| Drop Specification |
Multiple 6 ft./1.8 m drops per MIL-STD 810Gspecifications |
| Electrostatic Discharge (ESD) |
15KV Air8KV Touch |
| Environmental Sealing |
IP64 per IEC sealing specifications |
| Humidity |
95% non-condensing |
| Operating Temperature |
14° F to 122° F/-10° C to 50° C |
| Storage Temperature |
-40° F to 158° F/-40° C to 70° C |
| Tumble Specification |
1000 1.6 ft./0.5 m tumbles (equivalent to 2,000 hits) perIEC tumble specifications |
|
| Physical Characteristics |
| Audio |
Speaker, microphone, receiver (for handset mode use)and Bluetooth audio headsets |
| Color Camera |
Resolution 3.2 megapixelIllumination User controllable flash Lens Auto focus |
| Dimensions (W x H x D) |
With rechargeable 2400 mAhLithium Ion battery:5.78 in. L x 3.03 in. W x 1.06 in. D147 mm L x 77 mm W x 27 mm D |
| Display |
PenTile® 3.5 in Color VGA,super bright 650+ NITS |
| Expansion Slot |
microSD slot (maximum 32GB) |
| Keypad |
Numeric, QWERTY, AZERTY and QWERTZ |
| Touch Panel |
Glass analog resistive touch |
| Weight |
11.1 oz./315 g (with rechargeable2400 mAh Lithium Ion battery) |
