| Performance Characteristics |
| 2D Imager Engine (SE4500) |
Roll Tolerance: 360° |
|
Skew Tolerance: ± 60° from normal |
|
Pitch Tolerance: ± 60° from normal |
|
Sensor Resolution: 752 x 480 pixels |
|
Aiming Element (VLD): 655 nm ± 10 nm Laser |
|
Field of View: Horizontal 40°; Vertical 25° |
|
Field of View: Horizontal: 39.6°; Vertical: 25.7° |
|
Illumination Element (LED):625 nm ± 5 nm LEDs (2x) |
|
Optical Resolution: WVGA 752H X 480V pixels (gray scale) |
|
Focal Distance: From center of exit window: SR – 7.5 in./19 cm |
| Communication Interface |
USB 2.0 High Speed (host and client) |
| CPU/Processor |
MSM Qualcomm 7627@ 600 MHz (multi-processor architecture) |
| Memory |
512MB RAM/1GB Flash |
| Notification |
Audible tone plus multi-color LEDs |
| Operating System |
Microsoft Windows® Embedded HandHeld 6.5 |
|
| Communication Modules |
| Integrated GPS |
GPS: Integrated standalone or Assisted-GPS (A-GPS) with gpsOneXTRATM |
| Wireless LAN Voice and Data Communications |
Radio: Tri-mode IEEE® 802.11a/b/g |
|
Data Rates Supported: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48 and 54 Mbps |
|
Security: WPA2 (Personal or Enterprise); 802.1x; EAP-TLS; TTLS (CHAP, MS-CHAP, MS-CHAPv2, PAP or MD5); PEAP (TLS, MSCHAPv2, EAP-GTC); LEAP, EAP-FAST (TLS, MS-CHAPv2, EAP-GTC) |
|
Voice Communication: Voice-over-IP ready, Wi-Fi™-certified, IEEE 802.11a/b/g direct sequence wireless LAN, Wi-Fi Multimedia™ (WMM and WMM-PS) Motorola Voice Quality Manager ( |
| Wireless PAN Data and Voice Communications |
Bluetooth: Class II, v2.0 with Enhanced Data Rate (EDR) |
| Wireless WAN Voice & Data Communications |
Radio: Dual 3.5G: GSM HSPA/HSUPA and CDMA EVDO Rev A |
|
Frequency Band: UMTS/HSDPA and HSUPA: 850, 1900 and 2100 MHz GSM/EDGE: 850, 900, 1800 and 1900 MHz CDMA/EVDO Rev A: 850 and 1900 MHz |
|
| Data Capture Characteristics |
| Data Types |
1D and 2D bar codes, photographs, video, signatures, documents |
| DL Focus Range |
Range : Near : Far:-5 mil Code 39: 1.4 in./36 mm 7.3 in./185 mm |
|
100% UPC/EAN: 1.6 in./41 mm 12 in./305 mm |
|
5 mil PDF417: 2.8 in./71 mm 4.5 in./114 mm |
| Options |
Three configurations available: 2D SE4500-SR imager; 2D SE4500-SR imager + 3.2 MP Camera; 2D SE4500-DL imager + 3.2 MP Camera |
| SR Focus Range |
Range : Near : Far:-5 mil Code 39: 2.1 in./53 mm 7.5 in./191 mm |
|
100% UPC/EAN: 1.6 in./41 mm 15.5 in./394 mm |
|
6.7 mil PDF417: 3.4 in./86 mm 7.1 in./180 mm |
|
| Power Specifications |
| Backup Battery |
Li-Mn02 (rechargeable) 25mAh 3.0V (not user-accessible or replaceable) |
| Battery Performance |
Talk Time: 6 Hours |
|
Standby Time: 100 Hours |
|
User Profiles: 8 Hours (user profile dependent) |
| Standard Battery |
Rechargeable Lithium Ion 3.7V, 3600 mAh battery; |
|
| Environment Characteristics |
| Ambient Light (from total darkness) |
Sunlight: 8000 ft. candles |
|
Fluorescent: 450 ft. candles |
|
Indoor: 450 ft. candles (4845 lux) |
|
Outdoor: 9000 ft. candles (96,900 lux) |
| Drop Specification |
Multiple 6 ft. drops per MIL-STD 810G specifications |
| Electrostatic Discharge (ESD) |
± 8kv indirect discharge |
|
± 15kv Air discharge, ± 8kv direct discharge, |
| Environmental Sealing |
IP64; per applicable IEC sealing specifications |
| Humidity |
5 to 95% non-condensing |
| Interfaces |
Motorola Enterprise UI: customizable homescreen, enhanced dialer and enterprise camera solution |
| Operating Temperature |
14° F to 122° F/-10° C to 50° C |
| Storage Temperature |
-40° F to 158° F/-40° C to 70° C |
| Tumble Specification |
1,000 1.6 ft./0.5 meter tumbles (2,000 drops) at room temperature; per applicable IEC tumble specifications |
| Vibration |
4g’s PK Sine (5Hz to 2KHz); 0.04g2/Hz Random(20Hz to 2KHz); 60 minute duration per axis, 3 axis |
| Voice and Audio |
VoWWAN; VoWLAN; PTT, VoIP-ready; high- quality speakerphone; support for wireless (Bluetooth) headsets; support for PTT headsets, handset and speaker phone modes |
|
| Physical Characteristics |
| Audio |
Dual microphone support with noise cancellation; vibrate alert; speaker; Bluetooth headset |
| Backlight |
LED backlight |
| Camera |
Resolution: 3.2 megapixel |
|
Lens: Autofocus |
|
Illumination: User controllable flash |
| Dimensions (W x H x D) |
6.38 in. L x 3.03 in. W x 1.32 in. D (with antenna)162.2 mm L x 77 mm W x 33.5 mm D (with antenna) |
| Display |
PenTile® 3.5 in Color VGA,super bright 650+ NITS |
| Expansion Slot |
microSD slot (supports up to 32GB) |
| Keypad |
Keypad Options: Numeric, QWERTY, AZERTY, QWERTZ, PIM and DSD |
| Touch Panel |
Glass analog resistive touch |
| Weight |
12.5 oz./359g (with rechargeable 3600mAh Lithium Ion battery |
