| Performance Characteristics |
| Applications Development |
PSDK and EMDK available |
| CPU/Processor |
Marvell PXA320 processor at 806 MHz |
| Memory |
(RAM/ROM) 256MB/1GB |
| Operating System |
Microsoft Windows CE 6.0 orMicrosoft Windows Mobile 6.5 Classic |
|
| Communication Modules |
| WLAN |
radio : 802.11a/b/gData Rate : 802.11a: up to 54 Mbps; 802.11b: up to11 Mbps; 802.11g: up to 54 MbpsFrequency Range : All country dependent: 802.11a – 5 GHz;802.11b – 2.4 GHz; 802.11g – 2.4 GHz |
| WLAN Antennas |
Antenna Internal |
| WLAN Security |
WPA2 Enterprise, 802.1x; EAP-TLS; TTLS(CHAP, MS-CHAP, MS-CHAPv2, PAP orMD5); PEAP (TLS, MSCHAPv2, EAP-GTC);LEAP, EAP-FAST (TLS, MS-CHAPv2, EAPGTC),WPA2/AES, CCX v4, FIPS 140-2 andIPv6 |
| WPAN Radio |
PAN (Bluetooth) Bluetooth Version 2.1 with EDR |
|
| Data Capture Characteristics |
| Data Capture Options |
SE960: 1D1 standard range scan engineSE1524-ER: 1D3 extended range scan enginereads up to 45 ft./13.72 m awaySE4500: Omnidirectional 1D/2D imagingengine reads 1D and 2D symbolsSE4600: Extended range omnidirectional1D/2D imaging engine reads 1D and 2Dsymbols as close as 8 in./20.32 cm and asfar as 30 ft./9.14 mSE4500-DL: 1D/2D DL imaging engine readsall 1D and 2D codes as well as the PDFcodes found on driver’s licenses and otheridentification documentsSE4500-HD: 1D/2D DPM imaging enginereads a wide variety of DPM marks onmetal, plastic and glass surfaces, including:dot peening, laser etching, molding, stampingor casting |
|
| Power Specifications |
| Cradle |
Single-slot Serial/USB, 4-slot Ethernet,4-slot charge only, forklift |
| Power Supply |
Removable, rechargeable 7.2 volt Lithium Ion2200 mAh battery pack, 15.8 watt hours |
|
| Environment Characteristics |
| Drop Specification |
Multiple drops to concrete: 6 ft./1.8 macross the operating temperature range;meets and exceeds MIL-STD 810G |
| Electrostatic Discharge (ESD) |
±15kVdc air discharge; ±8kVdc directdischarge; ±8kVdc indirect discharge |
| Environmental Sealing |
IP64 (electronic enclosure, display and keypad)per IEC Sealing Specification |
| Humidity |
5% to 95% non condensing (CondensationResistant Configurations Available) |
| Operating Temperature |
-4° to 122° F/-20° to 50° CCharging Temp. 32° to 104° F/0° to 40° C |
| Storage Temperature |
-40° F to 158° F/-40° C to 70° C |
| Tumble Specification |
2,000 3.28 ft./1 m tumbles at roomtemperature (4,000 hits) per IEC TumbleSpecification |
