| Performance Characteristics |
| Application Software |
Internet Explorer® 6 for CEWordpadActive SyncOpen TekTermANSI emulationTESS terminal emulationsIBM 3270, IBM 5250, HP 2392 |
| CPU/Processor |
Marvell® XScale® PXA 270,520 MHz |
| External Ports |
Tether port with:RS232 serial (decoded/undecoded scanner, printer)USB hostDocking Station Port with:RS232 serialUSB device supportUSB host supportPower in/out |
| Indicators and Controls |
Internal 95 dBA beeper withvolume controlMulticolor LEDs for radiotransmit/receive, scanningbattery status, userapplications |
| Memory |
64 MB Flash ROM128 MB RAM |
| Operating System |
Windows® CE 5.0 |
|
| Communication Modules |
| RFID Applications |
Multi-protocol support @ 900MHz North America / 868 MHzEurope / 952 MHz Japan / 920MHz China |
| Wireless Communications |
802.11 b/g Compact Flash Radiooperating in 2.4 GHz band (CCXCertified v.4)802.11a/b/g Compact FlashRadio with integrated antennaoperating in 2.4 GHz and 5 GHzbandsOn-board Bluetooth® radio 2.4GHz (10m range) |
|
| Data Capture Characteristics |
| Internal Barcode Scanners |
1D Standard Range Laser1D Standard Range Fuzzy LogicLaser1D Long Range Laser1D Advanced Long Range Laser1D Auto-Ranging LaserPDF417 Raster Laser1D Imager2D Imager |
|
| Power Specifications |
| Battery Performance |
8 hour battery operation (5scans, transmit & receive/min)Smart Battery System Level 3compliantBuilt-in gas gauge &performance monitorQuick swap battery packsBuilt-in fast charger (1.75 hourtypical recharge)Self-guiding & latching batterypack designSystem backup (up to 20minutes) during battery swap 1 week real-time clock backupAdjustable battery allocationbetween system backup andruntime |
| Standard Battery |
7.4V @ 1900mAh Li-ionrechargeable battery |
|
| Environment Characteristics |
| Cradle Shock |
Cradle shock: IEC 60068-2-27:Test Ea, 300 m/s2, 11ms,half-sine, 3 shocks in each of 6directions |
| Cradle Vibration |
Cradle vibration: IEC 60068-2-64: Test Fh, Random, 3 axis;5.0 m2/s3 ASD, 10-200 Hz; 1.0m2/s3 ASD, 200 – 500 Hz |
| Drop Specification |
Drop Rating: Withstandsmultiple drops from 6 ft (1.8m)or 26 drops (on 12 edges,6 corners, 8 faces) from 5ft (1.5m) to concrete whilepowered on and configuredwith accessories such as WiFiradio, scanner/imager andpistol grip. |
| Environmental Sealing |
Rain/Dust: IEC 529,classification IP65 |
| Humidity |
Humidity: 5% – 95% RH noncondensing |
| Operating Temperature |
Operating temp: 14°F to 122°F(-10°C to +50°C) |
| Storage Temperature |
Storage temp: -13°F to 140°F(-25°C to +60°C) |
|
| Physical Characteristics |
| Dimensions (W x H x D) |
Size: 10.24” L x 4” W x 2.5”D (260mmL x 102mmW x62.5mmD)Keypad area: 3”W x 1.4” D(76mm W x 36mm D) |
| Display |
Display:1?4 VGA portrait mode,160 cd/m2Automatic backlight & contrastcontrolSunlight readable – brightdisplay (for outdoor use)Hi-reliability white LEDbacklight (1.5 ft-L)Color:3.5” (8.9cm) 240 x 320graphic transflextive TFT256K displayable colorsMonochrome:3.5” (8.9cm) 240 x 320 TFTBlack on white |
| Internal Expansion Slots |
One SD memory card slotOne Type II Compact Flash slot |
| Keyboards |
2 ABCD formats availableStandard 58 key alpha(6 single push function keys,30 addressable)Optional 36 large key (10single push function keys, 30addressable)EL Keypad backlightErgonomic ambidextrous onehandoperationHard-capped keys (rated at1M+ cycles) |
| Touchscreen Options |
Touchscreen:Plastic 4-wire (1 milliontouches)Glass 5-wire (20 milliontouches)Passive stylus or fingeroperationIntegral stylus holder |
| Weight |
Weight with battery: 24.87oz(705g), Pistol grip – add:3.05oz (86g) |
|
| Options |
| Regulatory Approvals |
Safety: UL 1950, CSA C22.2No950, LVD EN60950 |
|
EMC: FCC Part 15 Class B, EMCDirective Class B |
|
Laser: IEC 825-1 Class 2(EN60825-1), 21CFR1040Class II |
