| Performance Characteristics |
| Application Software |
Internet Explorer® 6 for CEWordpadActive SyncOpen TekTermANSI emulationTESS terminal emulationsIBM 3270, IBM 5250, HP 2392 |
| CPU/Processor |
Marvell® XScale® PXA 270,520 MHz |
| External Ports |
Tether port with:RS232 serial (decoded/undecoded scanner, printer)USB hostDocking Station Port with: RS232 serialUSB device supportUSB host supportPower in/out |
| Indicators and Controls |
Multicolour LEDs for radiotransmit/ receive, scanning,battery status, userapplications |
| Memory |
64 MB Flash ROM128 MB RAM |
| Operating System |
Windows® CE 5 |
|
| Communication Modules |
| Network Management & Security |
SNMP MIB 2 supportRemote software downloadRemote WLAN managementEnhanced security for 802.11 |
| RFID Applications |
Multi-protocol support@ 900 MHz |
| Wireless Communications |
802.11 b/g Direct Sequence(DS) – Extended Range Compact Flash (CCX-Certified)Security:WPA 1, 801.11i/WPA 2Encryption – DynamicWEP, AESEAP Types – LEAP, PEAPMS-CHAP v2, PEAP GTC,EAP-FAST,TLS,TTLS.Narrowband 403-512MHz PC Card radio |
|
| Data Capture Characteristics |
| Internal Barcode Scanners |
1D Standard Range Laser1D Standard Range Fuzzy LogicLaser1D Long Range Laser1D Advanced Long Range Laser1D Auto-Ranging LaserPDF417 Raster Laser1D Imager2D Imager |
|
| Power Specifications |
| Battery Performance |
Quick swap packsAdvanced Smart Battery withgas gaugeBuilt-in fast charger (2hrs)System backup during batteryswap (15 min)1 week real-time clock backup |
| Extended Battery |
Optional Li-Ion High Capacitybattery (11.1 V, 2400 mAh, up to17 hrs usage) |
| Standard Battery |
Li-Ion standard battery (11.1 V,1900 mAh, up to 12 hrs usage) |
|
| Environment Characteristics |
| Cradle Shock |
30g in each axis |
| Cradle Vibration |
50g RMS PSD(4 – 500 Hz) (random) |
| Drop Specification |
Drop Rating: 6’ (1.8m) – multipledrops, plus 5’ (1.5m) – 26 dropsto polished concrete. |
| Environmental Sealing |
Rain/Dust: IEC 529,classification IP67 |
| Humidity |
Humidity: 5% – 95% RHCondensing |
| Operating Temperature |
Operating temp: -22°F to 140°F(-30°C to +60°C) |
| Storage Temperature |
Storage temp: -40°F to 140°F(-40°C to +60°C) |
|
| Physical Characteristics |
| Audio |
Sound:Voice Features – speaker andmicRecord/playback emailattachments |
| Dimensions (W x H x D) |
Size: 10.6”L x 3.9”W x 3.3”D(270mmL x 100mmW x85mmD)• Keypad grip area: 3”W x 1.7”D(77mmW x 43mmD) |
| Display |
1?4 VGA portrait mode,160 cd/m2Automatic backlight & contrastcontrolSunlight readable – brightdisplay (for outdoor use)Color 3.5” (8.9cm) 240 x 320graphic transflextive TFT256K displayable colorsHi-reliability white LEDbacklight (1.5 ft-L) |
| Internal Expansion Slots |
One SD I/O (MultiMediaCard)slotOne Type II Compact Flash slotOne Type III Extended PC Cardslot |
| Keyboards |
2 formats available37 key large button (10F-keys)63 key alpha (10 F-keys)Illuminated with EL backlightErgonomic ambidextrous onehandoperation with dual EnterkeysDedicated function keysHard-capped keysElastomer keys |
| Touchscreen Options |
Ultra-rugged 5-wire technologyPassive stylus or fingeroperationSignature captureIntegral stylus holder |
| Weight |
Weight: 37.39oz ( 1060g)Includes std. battery, stdradio & std. internal scannerPistol grip add 4oz (125g) |
|
| Options |
| Regulatory Approvals |
Laser: IEC 60825-1 2001 Class 2 (EN60825-1) |
|
Safety: UL 1950, CSA C22.2No950, LVD N60950 |
|
EMC: FCC Part 15 Class B, EMCDirective Class B |
| User Options |
Optional frost free scan window |
