| Printing Characteristics |
| Print Method |
Direct Thermal/Thermal Transfer |
| Print Speed |
100mm/sec (4ips) |
| Print Width |
WxP): 56 x 400mm (2.20” x 15.75”) |
| Resolution |
8 dots/mm (203dpi) |
|
| Media Characteristics |
| Label Length |
6 to 600mm (0.23” to 23.62“), |
| Media Roll Diameter |
130mm (Paper core: 40mm) / 115mm (Paper core: 26.9mm) |
| Media Sensor |
I-Mark Sensor (Reflection type), Label Gap Sensor (Transmissive type) |
| Media Thickness |
0.06 to 0.19mm (0.0024” to 0.0075”) * Does not apply to wristbands |
| Media Width |
12 to 60 mm (0.47” to 2.36”) |
|
| Ribbon Characteristics |
| Ribbon Roll Diameter |
38mm (1.50”), |
| Ribbon Width |
Width: 59mm (2.32”) |
| Core Inner Diameter |
12.7mm (0.50”) |
|
| Performance Characteristics |
| Interface |
USB + RS-232C model, USB + LAN model * RS-232C is able to connect to PC or SATO Keypad. Optional: External Wireless LAN |
| Memory |
Main Memory (Flash ROM): 4MB, RAM: 8MB |
| Processor |
32 Bits RISC-CPU |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:UPC-A/UPC-E, JAN/EAN, CODE39, CODE93, CODE128, GS1-128(UCC/EAN128), CODABAR(NW-7), ITF, Industrial 2of5, Matrix 2of5, BOOKLAND, MSI, POSTNET, GS1 DataBar(RSS) barcode |
|
2D:QR code, MicroQR, PDF417, MicroPDF, MAXI code, GS1 DataMatrix (ECC200) |
| Character Sets |
XU, XS, XM, XB, XL, OCR-B, OCR-A (15×22), OCR-B (20×24), OCR-A (22×33), OCR-B (30×36), CG Times, CG Triumvirate |
| Enlargement & Rotation |
Character: 0º, 90º, 180º, 270º rotation per each data is available Barcode: Parallel 1 (0º), Parallel 2 (180º), Serial 1 (190º), Serial 2 (270º |
|
| Environment Characteristics |
| Operating Environment |
0 ~ 35ºC / 30 ~ 80% RH (without condensing) |
| Storage Environment |
-10 ~ 60ºC / 15 ~ 85% RH (without condensing) |
| User Options |
Cutter, Dispenser, RFID HF Kit, Wireless LAN (802.11 b/g auto switching), Keypad, Unwinder, SATO Label Gallery™ |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
(WxDxH): 128 x 235 x 173mm (5.04” x 9.25” x 6.81”) |
| Power Requirements |
Input voltage: AC100V-240V±10%, Frequency: 50/60Hz, Output voltage: DC19V±5%, 3A |
| Weight |
TT model (about 1.6kg/3.5Ibs), DT model (about 1.5kg/3.3Ibs) |
|
| Options |
| Regulatory Approvals |
USA/CANADA: FCC15B Class B, EUROPE: CE (EN55022, EN55024), CHINA: GB9254-1998, GB17625.1(2003, SINGAPORE: CISPR22, CISPR24, KOREA: KN22, KN24, Other Standard: RoHs compliant, Electrical Power Saving (International Energy Star Programme, at usage of AC Adaptor) |
