| Printing Characteristics |
| Print Method |
Direct Thermal/Thermal Transfer |
| Print Speed |
100mm/sec (4ips) |
| Print Width |
(WxP): 104 x 300mm (4.09” x 11.81”) |
| Resolution |
8 dots/mm (203dpi) |
|
| Media Characteristics |
| Label Length |
L: 7 ~ 300mm (0.28” ~ 11.81”), With backing paper: 10 ~ 303mm (0.39” ~ 11.93”) |
| Media Core Diameter |
Paper core inner diameter: 40mm (1.57”) |
| Media Roll Diameter |
Max external diameter: 128mm (5.04”), |
| Media Sensor |
I-Mark Sensor (Reflection type), Label Gap Sensor (Transparent type) |
| Media Thickness |
0.06 ~ 0.19mm (0.002” x 0.007 |
| Media Width |
W: 22 ~ 107mm (0.87” ~ 4.21”), With backing paper: 25 ~ 110mm (0.98” ~ 4.33”) |
|
| Ribbon Characteristics |
| Ribbon Length |
Max 100m |
| Ribbon Width |
110mm +/- 0.5mm (4.33” +/- 0.002) |
|
| Performance Characteristics |
| Interface |
USB (B Type) + RS-232C (D-SUB 9 Pin) Model, USB (B Type) + LAN (10BASE-T/100BASE-TX Auto Switching) Model, USB (B Type) + IEEE1284 Model |
| Memory |
Main Memory (Flash ROM): 4MB byte, SDRAM: 8MB byte |
| Processor |
32 Bits RISC-CPU 64MHz |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:UPC-A/ UPC-E, EAN8/13, CODE39, CODE93, CODE128, GS1-128 (UCC/EAN128), CODABAR(NW-7), ITF, INDUSTRIAL 2of5, MATRIX 2of5, BOOKLAND, MSI, POSTNET, GS1 DATABAR (RSS |
|
2D:PDF417 (Ver2.4), MAXI Code (Ver3.0), QR Code, GS1 Data Matrix (ECC200) |
| Character Sets |
Alphanumerical and Symbol: WB (18×30 dot), WL (28×52 dot), XU (5×9 dot), XS (17×17 dot), XM (24×24 dot), XB (48×48 dot), XL (48×48 dot), OCR-A (15×22 dot), OCR-A (22×23 dot), OCR-B (20×24 dot), OCR-B (30×36 dot) |
| Enlargement & Rotation |
Character & Barcode: 0º, 90º, 180º, 270º |
|
| Environment Characteristics |
| Operating Environment |
4 ~ 38ºC / 30 ~ 80% RH (without condensing) |
| Storage Environment |
-10 ~ 60ºC / 15 ~ 85% RH (without condensing) |
| User Options |
Cutter, Dispenser, RTC, Keypad , Unwinder, SATO Label Gallery™ |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
(WxDxH): 179 x 238 x 173mm (7.05” x 9.37” x 6.81”) Except protrusion part |
| Power Requirements |
Input Voltage: AC100V ~ 240V +/- 10%, Rated Input Voltage: AC100V / AC240V, Output Voltage: 19V |
| Weight |
DT: 1.7kg (3.5 Ibs) TT: 1.9kg (4.2 lbs) |
|
| Options |
| Regulatory Approvals |
USA/CANADA: UL60950-1 (2001), CSA22.2 No. 60950-1-03, EUROPE: EN60950-1, CE CHINA: CCC (GB4943-2001) |
