| Printing Characteristics |
| Print Length |
(W4.4” x L49.2″) |
| Print Method |
Direct Thermal / Left Hand |
| Print Speed |
Up to 125mm/sec (5ips) |
| Print Width |
W112mm x L1249mm |
| Resolution |
203dpi (8dpmm) |
|
| Media Characteristics |
| Media Sensor |
Reflective sensor for use with pre-printed eye-marks (bottom reading, fixed) / See-through Sensor (Gap), Movable |
| Media Thickness |
15 – 356mm (0.59-14″) [Web: 18 – 359mm (0.71 -14.13”)]Continuous: 0.1 – 0.25mm (0.003 – 0.009”); Dispense: 0.1 – 0.18mm (0.003 – 0.007”) |
| Media Width |
22-131mm (0.86-5.0″) |
|
| Performance Characteristics |
| Interface |
ECP Parallel (IEEE1284); Centronics Parallel, RS232C (2,400 – 19,200 Baud); RS232C Highspeed (9,600 – 57,600 Baud);USB (12Mbit/s); LAN (TCP/IP protocol 10/100 BaseT); Twinax/Coax, RS422/485; Wireless LAN 802.11b |
| Memory |
2.9Mb Input Buffer; 2Mb Flash MemoryInternal: 4Mb Flash Memory SIMM Card / External: up to 4MB S-RAM |
| Processor/CPU Type |
32-Bit RISC, 118MHz |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:UPC-A/E, EAN 8/13, CODE 39, 93 & 128, UCC/EAN 128, Interleaved 2/5, Industrial 2/5, Matrix 2/5, Codabar, MSI, Bookland, Postnet |
|
2D:Data Matrix, Maxicode, PDF417, QR-Code, RSS-14 |
| Graphics |
SATO Hex/Binary, .PCX Format & BMP Format |
|
| Environment Characteristics |
| Operation Environment |
5-40°C (41-104CF) non-condensing, 15-85% RH |
| Storage Environment |
-20-40°C (-4-104°F) non-condensing, Max 90% RH, ESD: 8kV |
| User Options |
Memory Expansion, Keyboard |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
W265 x D417 x H302mm(W10 x D16.4 x H11.9”) |
| Power Source |
110-120V / 200-240V, 50/60Hz; Idling: 50W; Operating: Max 700W |
| Weight |
11.5Kg (25!b.) |
|
| Options |
| Regulatory Approvals |
CE, TUV-GS, UL, CSA |
