| Printing Characteristics |
| Print Length |
2,286 mm (90″) |
| Print Method |
Direct Thermal and Thermal Transfer |
| Print Speed |
Upto6ips |
| Print Width |
108 mm (4.25″) |
| Printer Head |
TSPL-EZTM |
| Resolution |
203 DPI |
|
| Media Characteristics |
| Media Core Diameter |
25.4 -38.1 mm (1-1.5) |
| Media Sensor |
Gap transmissive sensor Moveable black mark reflective sensorHead open sensor Ribbon end sensor |
| Media Thickness |
0.06 – 0.19 mm (2.3 – 7.4 mil) |
| Media Type |
Continuous, Die-cut, fanfold, Linerless (DT only |
| Media Width |
25.4 ~ 112 mm (1-4.4) |
| Media Wound Type |
Outside wound |
|
| Ribbon Characteristics |
| Ribbon Roll Diameter |
67 mm 127mm (5″) OD |
| Core Inner Diameter |
110m 0.5 |
|
| Performance Characteristics |
| Interface |
Ethernet, USB, Parallel and Serial |
| Memory |
2 MB Flash; 8 MB SDRAM (SD Card slot for memory expansion |
| Processor |
32 bit RISC CPU |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:Code 39, Code 93, Code 128UCC, Code 128 subset A, B, C,Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A UPC-E, EAN and UPC 2 (5) digits add-on, MSI, PLESSEY, POSTNET |
|
2D:PDF-417, Maxicode, Datamatrix, QR Code |
| Character Sets |
Eight alpha-numeric bitmap fonts, One Monotype® Imaging CGTriumvirate Bold Condensed scalable font, Built-in Monotype® True Type Font engine |
| Enlargement & Rotation |
0,90,180 & 270 |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
(L x 258 mm x202 mm x173 mm |
|
| Options |
| Accessories |
BarTender UltraLite labeling software/ Driver CD disk Quick startguide USB cable External universal switching power supply Power cord |
| Regulatory Approvals |
FCC Class B, CE Class B, C-Tick Class B, UL, CUL, TUV/GS,CCC |
