| Printing Characteristics |
| Print Length |
Min. 0.16″ (4 mm)**; Max. 68” (1727 mm) |
| Print Method |
Thermal Transfer / Direct Thermal |
| Print Speed |
5 IPS (127 mm/s) |
| Print Width |
4.25” (108 mm] |
| Printer Head |
EZPL, GEPL, GZPL auto switch |
| Resolution |
203 dpi (8 dots/mm) |
|
| Media Characteristics |
| Media Core Diameter |
1″ (25.4 mm), 1.5″ (38.1 mm) |
| Media Roll Diameter |
Max. 5” (127 mm) |
| Media Sensor |
Adjustable reflective sensor (full range) Fixed transmissive sensor, central aligned |
| Media Thickness |
Min. 0.003″ (0.06 mm) – Max. 0.01″ (0.2 mm) |
| Media Type |
Continuous form, gap labels, black mark sensing and punched hole; label length set by auto sensing or programming |
| Media Width |
Min. 1″ (25.4 mm) – Max. 4.64″ (118 mm) |
|
| Ribbon Characteristics |
| Ribbon Length |
981′ (300 m) |
| Ribbon Roll Diameter |
Max. 2.67″ (68 mm) |
| Ribbon Type |
Wax, wax / resin, resin |
| Ribbon Width |
Min. 1.18″ (30 mm) – Max. 4.33″ (110 mm) |
| Core Inner Diameter |
1″ (25.4 mm) |
|
| Performance Characteristics |
| Interface |
USB 2.0 USB 2.0 USB 2.0 USB 2.0 Serial port: RS-232 (DB-9) Serial port: RS-232(DB-9) Serial port: RS-232 (DB-9) Serial port: RS-232(DB-9) Ethernet 10/100 Mbps Parallel port Ethernet 10/100 Mbps Parallel port |
| Memory |
8 MB Flash (4 MB for user storage)16 MB SDRAM |
| Operation Panel |
Two dual color LEDs (Ready 8. Status) Calibration button Control key: FEED Power on / off button |
| Processor |
32 bit RISC CPU |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:Code 39, Code 93, EAN 8/13 (add on 2 8.5), UPC A / E (add on 2 & 5), 1 2 of 5 & 1 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC / EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM and GS1 DataBar |
|
2D:PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code |
| Character Sets |
6,8,10,12,14,18,24,30,16X26 and OCR A&B Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable Bitmap fonts 8 times expandable in horizontal and vertical directions |
| Enlargement & Rotation |
Bitmap fonts 90°, 180°, 270° rotatable, sinqle characters 90°, 180°, 270° rotatable |
| Graphics |
Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software |
|
| Software |
| Driver / Utility |
Windows 2000, XP, Vista, 7, Windows Server 2003 & 2008 |
|
| Environment Characteristics |
| Humidity |
30-85%, non-condensinq10-90%, non-condensing |
| Operating Environment |
41 °F to 104°F (5°C to 40°C) |
| Storage Environment |
-4°F to 122°F (-20°C to 50°C] |
| User Options |
Guillotine Cutter Label Dispenser External label roll holder for 10″ (250 mm) O.D. label rolls |
