| Performance Characteristics |
| CPU/Processor |
80MHz RISC |
| Docking Station Optional |
RS232 port for point-to-point communicationModem interface to telephone lineEthernet Connectivity (TCP Client)Battery Charging Quick Charging typical 2~3 hoursPower Input AC/DC adapter @ 9VDC/2A |
| Indicator |
Light Source Visible Laser Diode 650nm |
| Interface |
Interface : RS232 communication portSupport TX/RX, CTS/RTS, GND, 150K-57.6K bpsHandshaking : Xon/Xoff or CTS/RTSProtocol : None, or Multi-point for multi-drop installationFile Transfer: Built-in Kermit serverBlueTooth :BT V2.0+ EDR( Enhanced Data Rate Compliant)WiFI :802.11 b/g (WEP & WPA-PSK & WPA2-PSK Security) |
| Memory |
RAM:512K/2.5MB/4.5MB/8.5MBFlashROM :256K with DOS-based system |
| Software Programming Tools |
C Language MSC, Borland C, Turbo CJobGen Plus A Windows-based program generator Form Caching A built-in program generatorDLL Library Available for 16/32-bit C++, VB, VFP and Delphi |
|
| Data Capture Characteristics |
| Decode Capabilities |
UPC-A/E, EAN-8/13, Codabar, Code 39,Code 39 full ASCI, Code 93,Code 32,Interleaved & Std. 2 of 5, EAN 128, Code 11,Delta, MSI/Plessey,Code 128, Toshiba, EAN 128 |
| Minimum Print Contrast |
Minimum 20% absolute dark/lightReflectance measured at 650 nm |
| Scanner Systems |
Laser Scanner (CCD Optional) |
| Scanning Angle |
53°±2° |
| Scanning Rate |
35 (±5) scans /sec (bi-directional) |
|
| Power Specifications |
| Backup Battery |
120mAH/3.6V for SRAM memory backup |
| Main Battery |
One rechargeable Lithium-ion battery pack@ 3.7V, 900mAH |
|
| Environment Characteristics |
| Drop Specification |
1.2 meters to floor |
| Environmental Sealing |
IP Rating IP54 |
| Operating Temperature |
Operation: -5°c to 50°c |
| Real Time Clock |
System date and time |
| Relative Humidity |
5% ~ 95% RH non-condensing |
| Storage Temperature |
Storage: -20°c to 70°c |
|
| Physical Characteristics |
| Audio |
Volume adjustable by software |
| Dimensions (W x H x D) |
165(L)mm*60(W)mm*35(H)mm |
| Display |
128×64 pixel |
| Keypad |
26 alphanumeric keys + one scan trigger |
| Weight |
230g with battery pack |
|
| Options |
| Accessories |
RS232 Communication CableUSB Communication Cable |
| Regulatory Approvals |
BSMI, CCC, CE, FCC, VCCI |
| User Options |
Li-ion recharging: 2.5 hours in Docking Station orthrough Charging CableOperating time:Over 12 hours,RoHS Compliant |
