| Printing Characteristics |
| Character Font/Character Sets |
Standard fonts: 25 bitmapped, 1 smooth, scalable (CG Triumvirateâ„¢ Bold Condensed)Optional fonts:Downloadable bitmapped and scalable fontsInternational character sets/codepages supported: USA, Germany, France, Sweden, Spain, Norway, Italy, CP850, UK, Latin9, Chinese (Simplified & Traditional),Japanese and Korean supported in 16 x 16 and 24 x 24.Thai (scalable) CP874. Others upon request. |
|
| Media Characteristics |
| Media Roll Diameter |
Max. Roll Size1.88″/47.8 mm O.D. on a .4″/10.2 mm to .75″/19 mmI.D. core |
| Media Thickness |
2 mil/.0508 mm to 4 mil/0.1016 mm |
| Media Type |
Direct thermal receipt paper, or UV coated media |
| Media Width |
Max. Media Width (MZ 220)2.0″ (+/- 0.03″)/50.8 mm (+/- 0.76 mm) |
|
| Performance Characteristics |
| Barcodes |
Linear Bar Codes: Code 39, Code 93,UCC/ EAN128,Code 128, Codabar (NW-7), Interleaved 2-of-5, UPC-A, UPC-E, 2 & 5 digit add-on, EAN-8, EAN-13, EAN14, 2 & 5 digit add-on2-Dimensional: Aztec, Maxicode, PDF-417, QR-Code, GS1 DataBar™(RSS) family*Contains UFST® from Monotype Imaging, Inc. |
| Battery |
1.5 Ah Li-Ion batteryShock-mounted internal components |
| Communication Modules |
USB 2.0 portSupported Internet Protocols: TCP, UDP, DHCP, FTP,Telnet, Http, LPD, SNMP, SMTP, POP3IrDA (standard)Bluetooth 2.0 (optional)802.11b/g (optional) |
| Graphic Features |
Supports user-defined fonts and graphics— including custom logos |
| Windows® Compatibility |
(CE.NET, Pocket PC, WindowsMobile 2002, Windows Mobile 2003 SE, Windows XP,2000 and NT via Zebra Windows printer driver and/orour Mobile SDK controls and other applications.) |
|
| Environment Characteristics |
| Drop Specification |
Resists repeated 4′ drops to concrete |
| Humidity (Operation) |
Operating Humidity 10-90% non-condensing |
| Operation Temperature |
Operating Temp. 14º F/-10º C to 122º F/50º C |
| Sealing |
IP42 rated for resistance to water |
| Storage Temperature |
Storage Environ. -4º F/-20º C to 140º F/60º C |
|
| Options |
| Accessories |
Protective silicone skinDurability enhancing caseShoulder strapVehicle adapter |
| Agency Approvals |
FCC Part 15 and EN55022 Class B limits; FCC, ICS, andEuropean Standards for Bluetooth and 802.11b/g; CSAand IEC 60950 standard for Safety; NOM, C-tick, VCCI,S-Mark, PSE, CCC, MII |
| User Options |
Bluetooth 2.0 connectivity802.11b/g connectivityMZ Series 4-Bay Power Station |
