| Printing Characteristics |
| Font/Character Sets |
Five resident scalable, rotatable fonts available from 12-48 pt.Downloadable soft fonts from Label Vista softwareOptional international character sets |
| Maximum Print Area |
Width: 1.89”/48.0 mmReceipt length: ContinuousLabel length: 32″/813 mm |
| Printer Language & Firmware |
CPCL-NativeZPL II-x.8EPL2XMLWavelink Avalanche® SupportMotorola® MSP SupportFile mirror via ftp or secure ftp |
| Printing Speed |
Maximum Print Speed 3”/76.2 mm per second |
| Resolution |
203 dpi/8 dots per mm |
|
| Media Characteristics |
| Max OD |
2.2”/55.9 mm |
| Media Specifications |
Label and liner width: .63”/16.0 mm to 2.18”/55.4 mm |
| Media Thickness |
Tag Receipt Thickness: 2.5 mil to 6.0 milLabel Thickness: 2.5 mil to 6.5 mil |
| Media Type |
Roll-fed, die-cut, linerless, receipt, fan-fold (QL 420 Plus) |
| Roll Core Inner |
3/4”/19.1 mm or 1-3/8”/34.9 mm |
|
| Performance Characteristics |
| Barcodes |
Linear Bar Codes:Code 39, Code 93, Code 128; Codabar; Interleaved 2-of-5; FIM Postnet; UPC-A UPC-E, 2 & 5 digit add-on; EAN-8, 13, 2 & 5 digit add-on; MSI/Plessey; UCC/EAN 1282-Dimensional: Aztec, Data Matrix, GS1 DataBar™ (RSS) family (12 bar codes), MaxiCode, PDF417, QR CodeContains UFST® from Monotype Imaging, Inc. |
| Battery |
7.4 V Lithium ion battery (2.1 Ah ) |
| Battery Charger |
External charger options |
| Communication Interface Capabilities |
Wireless security features (i.e. VPN or WPA/WPA2) 8 pin din (RS232C)Selectable baud rate: 9600 to 115.2 KbpsXon/Xoff or Hardware flow controlBluetooth optionWireless LAN (802.11b/g) |
| Graphic Features |
Graphics, line and box drawing features; PCX supported |
| Memory |
16 MB RAM; 8 MB Flash |
| Software |
ZebraDesigner™ ProZebraNet™ Bridge EnterpriseLabel VistaZebra Mobile SDK |
|
| Environment Characteristics |
| Operating Humidity |
10% to 80% non-condensing |
| Operation Temperature |
5º F/-15º C to 122º F/50º C |
| Sealing |
Water resistant : IP14 standards and IP54 rated with optional soft case |
| Storage Humidity |
10% to 90% non-condensing |
| Storage Temperature |
-13º F/-25º C to 158º F/70º C |
|
| Physical Characteristics |
| Dimensions (W x H x D) |
Width: 3.57”/90.7 mmDepth: 2.96”/75.2 mmHeight: 7.15”(w/o belt clip)/181.6 mm |
| Weight |
(with battery): 1.04 lbs./0.47 kg |
|
| Options |
| Accessories |
Spare lithium ion battery packsBattery chargers (AC/DC)Fanfold media bin (QL 420 Plus only)Mobile mount (QL 420 Plus only)Battery eliminatorSoft caseKickstandXML Support Applications and Documentation utility CD |
| Agency Approvals |
FCC and CE Class B compliance; design certified by CSA; CB Scheme report; NOM certified; C-Tick clearanceZebraLink |
| User Options |
802.11b/g wireless local area network (WLAN) or Bluetooth 2.0Media width auto-sensing featureLinerless printingInternational character sets |
