| Printing Characteristics |
| Font/Character Sets |
Standard fonts*: 25 bitmapped, 1 smooth, scalable (CG Triumvirate™ Bold Condensed)• Optional fonts: downloadable bitmapped andscalable fonts• International character sets (optional): Chinese 16 x 16 (trad), 16 x 16 (simplified), 24 x 24 (simplified); Japanese 16 x 16, 24 x 24, Hebrew/Arabic |
| Maximum Print Area |
Width4.09″/104mmLength Continuous |
| Printing Method |
Direct thermal |
| Printing Speed |
Maximum Print Speed3″/76.2 mm per second maximum |
| Resolution |
203 dpi/8 dots per mm |
|
| Media Characteristics |
| Media Roll Diameter |
Max. Roll Size (O.D.): 2.25″/57 mm |
| Media Thickness |
.002″/.05 mm to .0063″/.16 mm |
| Media Type |
direct thermal tags or receipt paper, synthetic media, UV coated media, limited label support |
| Media Width |
Media width2″/51 mm to 4.12″/105 mm standard |
| Roll Core Inner |
I.D. core: .75″/19 mm or 1.38″/ 34.9 mm |
|
| Performance Characteristics |
| Barcode Symbologies |
Linear Bar Codes: Code 39, Code 93, UCC/EAN- 128, EAN-14, Code 128, UPC-A, UPC-E, EAN-8, EAN-13,EAN-14, UPC and EAN 2-of-5 digital extensions, Plessey, FIM Postnet, Interleaved 2-of-5, MSI, Codabar2-Dimensional: Aztec, Data Matrix, GS1 DataBarâ„¢ (RSS) family (12 bar codes), MaxiCode, PDF417, QR Code |
| Battery |
|
| Communication Interface Capabilities |
Strain relief RS 232 serial interface |
| Connectivity |
Wavelink Avalanche®Motorola® MSP Native CPCL with ZPL®, EPL™, and XML support (standard) |
| Electrical |
Standard 4.0 Ah, 7.4V battery (RW 420)External charging options (vehicle and AC) Shock-mounted internal components Selectable baud rate: 9600 to 115.2 Kbps Xon/Xoff or hardware flow control (RTS/CTS)USB 2.0 full speed support, 12 Mbits/second (for setup and configuration)RS-232C serial port (RJ-45 connector) for cabled use |
| Graphic Features |
Supports user-defined fonts and graphics—including custom logos |
| Memory |
8 MB Flash, 16 MB RAM |
| Networking and Connectivity |
Bluetooth® v. 2.0802.11b/g Zebra Value RadioNative wireless security support: VPN, WPA/WPA2, WEP, Kerberos, WPA-PSK, EAP-TLS, EAP-TTLS,EAP-FAST, LEAP, PEAP, 802.11iRW 420 can be configured with dual radios (Bluetooth and WLAN)RW 420 can be configured with dual radios (Bluetooth and WLAN) |
| Software |
ZebraDesigner™ ProZebra Mobile SDKZebraNet™ Bridge EnterpriseZebra Universal DriverLabel VistaAuto-detect firmware loadBattery management (monitors battery for longer life and performance) |
|
| Environment Characteristics |
| Operating Humidity |
10-90% non-condensing |
| Operation Temperature |
-4º F/-20º C to 131º F/55º C |
| Sealing |
IP54-certified |
| Storage Humidity |
10-90% non-condensing |
| Storage Temperature |
-22º F/-30º C to 149º F/65º C |
|
| Physical Characteristics |
| Construction |
Impact-modified polycarbonate,abrasion-resistant rubber overmold |
| Dimensions (W x H x D) |
Base Version:Width: 6.3″/160 mmDepth: 3.0″/76 mmHeight: 6.9″/175 mmReader Version:Width: 6.3″/160 mm Depth: 3.1″/79 mmHeight: 6.9″/175 mm |
| Display |
LCD: Ergonomic, angled display for better viewing |
| Drop Specification |
6-foot multiple drops to concrete |
| Weight |
Base Version:Weight: 2.00 lbs./ 907 gReader Version:Weight: 2.15 lbs./ 975 g |
|
| Options |
| Accessories |
Magnetic stripe reader and EMV-certified smart card readerLithium Ion Fast AC ChargerLithium Ion Quad ChargerCigarette lighter charger (for in-vehicle charging)Vehicle cradle for docking and chargingShoulder Strap/Hand StrapEnvironmental Soft Case XML Support Applications and Documentationutility CD |
| Regulatory Approvals |
FCC Part 15 Class B, VCCI Class B, NOM/NYCE CE compliance (Class B), C-Tick, CSA |
| User Options |
Fanfold slot for accepting external media , Self-centering media holders,4-Bay Power StationRoute Palette |
