| Scanning Characteristics |
| Depth Of Field |
0-600 mm (Code39, PCS=90%, 20mil) |
| Print Contrast |
30% or more |
| Reading Perfomance |
Resolution: 4 mil :46 ~ 95 mm,5 mil:46 ~ 102 mm,10 mil :58 ~ 214 mm,13 mil : Up to 340 mm,20 mil : Up to 600 mm,40 mil :Up to 1,100 mm. |
| Scan Angle |
Front: 60° ,Rear: 60° ,Yaw: 75° |
| Scan Resolution |
0.1mm (4mil) Code39, PCS=90%, on contact |
| Scan Speed |
450 scan/sec |
| Scanning Width |
160mm |
|
| Performance Characteristics |
| Indicators |
Green & Red Led (2 more LED for 8520 cradle) |
| Light Source |
630nm Visible Red LED |
| Optical System |
2048 pixel CCD (charge-coupled device) |
| Program Upgrade |
Enabled by build-in flash memory |
| Programmable Characteristics |
Code type selection, check digit selection, Decoding option, Transmitted character delay, header selection, trailer selection, message suffix, good read beep tone and volume, scanner trigger selection Keyboard emulation type (intermessage delay, keyboard type and keyboard language) Serial interface type (ACK/NAK, Xon/Xoff, RTS/CTS, good read LED control, start/ stop bits) Cordless type (special cordless transmission character settings for 8020CL & 8520) |
| Programming Method |
Manual (Reading special barcodes) DOS command through RS232, Windows configuration program |
| Reading Indicators (Beeper Operation) |
7 tones or no beep |
|
| Communication Modules |
| Radio Frequency |
Type: GFSK Modulation Frequency: 2.4~2.483 GHZ Power: 0.25~2.5mw ; Adaptive Frequency System |
| Radio Range |
100 meters |
|
| Data Capture Characteristics |
| Decoding Capability |
Autodiscriminates all standard barcodes; including GS1 databar Other symbologies can be ordered optionally |
|
| Power Specifications |
| Battery Type |
32 mA @ 4.2 VDC |
| Current Consumption |
225 mA @ 4.2 VDC |
| Input Voltage |
5 VDC ± 0.25V |
| Operating Power |
900 mW |
| Standby Power |
150 mW |
|
| Environment Characteristics |
| Ambient Light Levels |
Up to 70000 lux |
| Contaminants |
Seals to resist airborne particulate contaminants ( IP 42 ) |
| EMC Regulation |
K C€ 0 — |
| Humidity |
10% to 90% relative humidity, non-condensing |
| Mechanical Shock |
1.5m drop onto concrete (90cm for 8520 cradle) |
| Operating Temperature |
0°C to 50°C (32°F to 122°F) |
| Storage Temperature |
-20°C to 70°C (-4°F to 158°F) (battery not included for 8510) |
|
| Physical Characteristics |
| Case Material |
ABS plastic (over molded at contact pointed) |
| Connector type |
RJ-45 phone jack connector |
| Dimensions |
Length 164 mmWidth-handle 30 mmWidth-head 78 mmDepth-handle 56 mmDepth-head 35 mm |
| Weight |
250g (battery included) |
