| Scanning Characteristics |
| Depth Of Field |
1D / Linear Codes:-5 mils: 1.3 to 6.4 cm / 0.5 to 2.5 in,7.5 mils: 1.3 to 11.4 cm / 0.5 to 4.5 in,10 mils: 0 to 15.2 cm / 0 to 6.0 in,13 mils: 0 to 20.3 cm / 0 to 8.0 in,20 mils: 0 to 22.9 cm / 0 to 9.0 in. |
|
2D Codes (Optional):6.6 mils: PDF: 3.8 to 10.2 cm / 1.5 to 4.0 in,10 mils: PDF: 0 to 18.0 cm / 0 to 7.0 in,15 mils: PDF: 0 to 20.3 cm / 0 to 8.0 in,10 mils: Data Matrix: 0 to 6.4 cm / 0 to 2.5 in,24 mils: Data Matrix: 0 to 20.3 cm / 0 to 8.0 in. |
| Print Contrast Ratio |
(Minimum) 25% |
| Read Rate |
(Maximum) 39 Million pixels per second |
| Reading Angle |
Pitch: +/- 65°; Roll (Tilt): 0 – 360°; Skew (Yaw): +/- 75° |
| Scan Resolution |
(Maximum) 5 mil |
| Width of Field |
Read Height 14.0 cm / 5.5 in |
|
| Performance Characteristics |
| Image Capture |
Graphic Formats: BMP, JPEG |
| Imager Sensor |
1280 x 1024 |
| Interface |
Interfaces IBM 46xx; Keyboard Wedge; OEM (IBM) USB; RS-232; USBAuxiliary Ports Powered RS-232 |
| Light Source |
Illumination: Multiple diffused 625nm LEDs |
| Reading Indicators (Beeper Operation) |
(Adjustable Tone and Volume); Good Read LED;Good Transmission |
|
| Data Capture Characteristics |
| Decoding Capability |
2D Codes: Aztec Code; Data Matrix (ECC 200 Only); MaxiCode; QR Code |
|
1D / Linear Codes :Autodiscriminates all standard 1D codes including GS1DataBar™ linear codes. |
|
Stacked Codes: GS1 DataBar Composites; GS1 DataBar Expanded Stacked;GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional;MicroPDF417; PDF417 |
|
| Power Specifications |
| AC Power Requirements |
AC Input: 90-264 VAC, 47-63 Hz |
| Power Consumption |
Operating (Maximum): 8.75 Watts; Operating (Nominal):2.8 WattsSleep Mode: 2.0 Watts |
|
| Environment Characteristics |
| Ambient Light Levels |
Ambient Light 0 – 86,100 lux |
| EAS Support |
Checkpoint Systems: Integrated EAS hardware will work withCounterpoint IX and Evolve D11 modelsSensormatic: Good Read Acknowledgement |
| Electrostatic Discharge (ESD Protection ) |
(Air Discharge) 25 kV |
| Humidity |
(Non-Condensing) 5 – 95% |
| Operating Temperature |
Temperature Operating: 0 to 40 °C / 32 to 104 °F |
| Storage Temperature |
Storage/Transport: -40 to 70 °C / -40 to 158 °F |
| Value Added Features |
Diagnostic Reporting; Host Download; Productivity IndexReporting™ (PIR) |
|
| Physical Characteristics |
| Dimensions |
14.2 x 15.2 x 8.2 cm / 5.6 x 6.0 x 3.2 in |
| Weight |
0.6 kg /1.3 lb |
|
| Options |
| Accessories |
Mounts/Stands:11-0405 Riser Mount11-0406 Table/Wall Mount |
| Regulatory Approvals |
The product meets necessary safety and regulatory approvalsfor its intended use.The Quick Reference Guide for this product can be referred tofor a complete list of certifications. |
| Safety Standards |
Environmental Compliance : Complies to China RoHS; Complies to EU RoHSLED Classification : EN 60825-1 Class 1 LED; IEC 60825-1 Class 1 LED Product |
| User Options |
Utilities:Magell an™ OS P Magellan On-Screen Programming (OSP) configurationsoftware is available for download at no charge.OPOS / JavaPOS JavaPOS Utilities are available for download at no charge.OPOS Utilities are available for download at no charge.Remote Host Download Lowers service costs and improves operations. |
