| Printing Characteristics |
| Character Sets |
(Font A, Font B) 32 characters, 42 characters |
| Characters Per Line |
Dots per line 384 dots per line |
| Print Width |
48 mm, 1.88 inches |
| Printer Class Size |
2-inch |
| Printing Method |
Line thermal dot printing |
| Printing Speed |
Up to 80 mm (3.1 inches) per second |
| Resolution |
203 dpi |
|
| Media Characteristics |
| Paper Roll Diameter |
up to 48 mm |
| Paper Width |
58 mm, 2.28 inches |
|
| Performance Characteristics |
| Battery |
Battery type and capacity Li-Ion, 7.4 volt, 1900 mAh |
| Battery Charger Specification |
Input: 100V-240V AC, 50/60Hz. Output: 8.4 volts, 1200 mA |
| Connectivity |
Interface versions :RS232C Serial :Standard. Up to 115,000 bps, 7 or 8 bit, 8-pin mini-DIN connectorUSB: Standard. USB 2.0, mini connector, type BBluetooth :Factory Option. Class 2, v2.0, 2.4Ghz FH, 10 metres, up to 115Kbps, SPP profileWireless LAN :Factory Option. 802.11b and 802.11g standards, 100 metres, 64/128 bit WEP,WPA, up to 54Mbps |
| Drivers |
Windows compatible drivers for desktop and mobile operating systems |
| Emulation |
ESC/POS™ |
| Readers |
Magnetic Stripe Reader :Factory Option. ISO 7811/2, JIS standards. Dual track (1+2, 2+3), 10-15 cm/sswipe speedIC-Card Reader: Factory Option. 9,600 bps read speed, internal 1-channel. |
|
| Physical Characteristics |
| Case Design |
High-impact ABS plastic |
| Dimensions (W x H x D) |
96 x 136 x 58 mm 120 x 70 x 152 mm |
| Drop Rating |
Environmental rating, drop test Exceeds IP42. Survives multiple drops of 1.5 metres. |
| Weight |
(inc. battery, excl. paper) 442 grams (approx. 0.44 Kgs, 1.0 lb) |
