| Scanning Characteristics |
| Depth Of Field |
Read Height 15.2 cm / 6.0 in |
| Read Rate |
(Maximum) 6,400 scan lines/sec.Scan Lines 64Sides Read 6 Sides – SurroundScan 3D Scanning™ |
| Scan Angle |
Scan Zone 360° x 2 |
|
| Performance Characteristics |
| Indicators |
Good Read LED |
| Interface Ports |
Auxiliary Ports:EAS Port; Powered RS-232; Remote Scale Display; Scale Host;Sensormatic EAS Controller Port |
|
RS -232 / IBM 46XX / USBMulti-Interface :OEM (IBM) USB Plus Power (Scanner and Scale);RS-232 (Scanner) / RS-232 (Scale); RS-232 (Scanner) or SingleCable RS-232 (Scanner and Scale) |
| Motor Speed |
Motor Speed 6,000 rpm |
| Reading Indicators (Beeper Operation) |
Adjustable Tone and Volume |
|
| Data Capture Characteristics |
| Decoding Capability |
1D / Linear Codes : Autodiscriminates all standard 1D codes including GS1DataBar™ linear codes. |
|
Stacked Codes : GS1 DataBar Expanded Stacked; GS1 DataBar Stacked;GS1 DataBar Stacked Omnidirectional |
|
| Power Specifications |
| AC Power Requirements |
AC Input: 100 – 250 VAC 50 HzPower Consumption: Operating (Maximum): 17 WattsOperating (Nominal): 9 Watts |
|
| Environment Characteristics |
| Humidity |
5 – 95% |
| Operating Temperature |
10 to 40 °C / 50 to 104 °F |
| Optional Features |
All -Weighs Scale Platter Produce Rail™EAS Features :Checkpoint Systems: Integrated EAS hardware will work withCounterpoint IX and Evolve D11 modelsSensormatic: Datalogic SmartSentry™ Firmware Interfaceswith the Sensormatic AMB-9010 EAS Deactivation Controller;Good Read Acknowledgement; Integrated EAS Antenna in theVertical and Horizontal PlaneMagell an Scale Technology : Dual Interval Scale; Single Interval ScalePreScan™ Queue-Busting Software : Single and Multi-Lane ConfigurationsRemote Sc ale Displ ay Dual Display with (20.3 cm / 8.0 in) PostSingle Display : with (20.3 cm / 8.0 in) PostValue Added Features : Cashier Training™; Diagnostic Reporting; Host Download;Productivity Index Reporting™ (PIR) |
| Storage Temperature |
Storage/Transport: -40 to 70 °C / -40 to 158 °F |
|
| Physical Characteristics |
| Dimensions |
Depth (Below Counter): 12.7 cm / 5.0 inHeight (Above Counter): 17.8 cm / 7.0 inLength: Model 8503 (Long, Scanner Only): 50.8 cm / 20.0 inModel 8504 (Long, Scanner/Scale): 50.8 cm / 20.0 inModel 8505 (Short, Scanner Only): 42.2 cm / 16.6 inWidth: 29.2 cm / 11.5 in |
| Scale Capacities |
Adjustments Required: Calibration Only (Unless in EC countrieswhere pre-verification is allowed)Capacity: Dual Interval Scale: Range 1: 0 – 6.0 kg / 0 – 12.0 lb;Range 2: 6.0 – 15.0 kg / 12.0 – 30.0 lbSingle Interval Scale: 0 – 15.0 kg / 0 – 30.0 lbMaximum Static Weight: 68.0 kg / 150.0 lbMinimum Increment: Dual Interval Scale: Increment 1: 0.002kg / 0.005 lbIncrement 2: 0.005 kg / 0.010 lbSingle Interval Scale: 0.005 kg / 0.010 lb |
| Weight |
Vibration Immunity: 4 Programmable Filter SettingsModel 8503 (Long, Scanner Only): 9.1 kg / 20.0 lbModel 8504 (Long, Scanner/Scale): 11.8 kg / 26.0 lbModel 8505 (Short, Scanner Only): 8.2 kg / 18.0 lb |
|
| Options |
| Accessories |
11-0373: Remote Scale Display, Single Head ;11-0375: Remote Scale Display, Dual Head |
| Agency Approvals |
The product meets necessary safety and regulatory approvalsfor its intended use.The Quick Reference Guide for this product can be referred tofor a complete list of certifications. |
| Safety Standards |
Environmental Compl iance Complies to China RoHS; Complies to EU RoHSLaser Classification : Caution Laser Radiation – Do not stare into beam; CDRH Class IIa |
| User Options |
UtilitiesOPOS / JavaPOS JavaPOS Utilities are available for download at no charge.OPOS Utilities are available for download at no charge. |
