| Scanning Characteristics |
| Depth Of Field |
150 mm (Code 39, 500Lux, PCS=90%, 20mils) |
| Print Contrast |
45% or more |
| Scan Angle |
Pitch: Max 60° ,Yaw: Max 70° |
| Scan Resolution |
0.1mm(4mils) – Code 39, PCS=90 % |
| Scan Speed |
100 scans/sec |
| Scanning Width |
95mm wide @ 55mm distance50mm wide @ 10mm |
|
| Performance Characteristics |
| Indicators |
Green LED |
| Light Source |
660 nm visible red LED |
| Optical System |
2048 pixel CCD (charge-coupled device) |
| Programmable Characteristics |
Code type selection, check digit selection decoding option transmitted character delay,header selection, trailer selection, message suffix, good read beep tone and volume,scanner trigger selection keyboard emulation type (intermessage delay, keyboard type andkeyboard language).Serial interface type (ACK/NAK, Xon/Xoff, RTS/CTS, good read LEDcontrol, start/stop bits) |
| Programming Method |
Manual (reading special barcode) |
| Reading Indicators (Beeper Operation) |
7 tones or no beep |
|
| Data Capture Characteristics |
| Decoding Capability |
Autodiscriminates all standard onedimensionbarcodes; including GS1 databar |
|
| Power Specifications |
| Current Consumption |
Current – operatingMAx 250 mA @ 5 VDCCurrent – standby30 mA @ 5 VDC |
| DC Transformers |
Class 2; 5VDC @ 500 mA |
| Input Voltage |
5 VDC ± 0.25V |
| Operating Power |
Max 250mA |
| Standby Power |
30 mA @ 5 VDC |
|
| Environment Characteristics |
| Ambient Light Levels |
Up to 20000 Lux |
| Contaminants |
Sealed to resist airborne particulate contaminants |
| Humidity |
10% to 90% relative humidity, non-condensing |
| Mechanical Shock |
1.5m drop onto concrete |
| Operating Temperature |
0°C to 45°C (32°F to 113°F) |
| Shock Resistance |
0°C to 45°C (32°F to 113°F) |
| Storage Temperature |
-20°C to 60°C (-4°F to 140°F) |
|
| Physical Characteristics |
| Cable – K/B wedge,RS-232,USB |
Straight 2.0 m (fixed) |
| Case Material |
ABS plastic + TPR |
| Connector type |
Crimp type female connector |
| Dimensions |
Length 176 mmDepth-handle 30 mmDepth-head 40 mm |
| Weight |
90 g (cable not included) |
