| Printing Characteristics |
| Print Length |
0.375” – 99” (9.5mm – 2514mm) |
| Print Method |
Direct thermal; optional thermal transfer |
| Print Speed |
4ips (101mm/s) |
| Print Width |
4.25” (108 mm) @ 203dpi (8 dots/mm); 4.16”(106 mm) @ 300dpi (12 dots/mm) |
| Resolution |
203 dpi (8 dots/mm) – Optional 300 dpi (12 dots/mm) |
|
| Media Characteristics |
| Media Core Diameter |
Min: 1” (25 mm) / Max: 1.5” (38 mm) |
| Media Roll Diameter |
5” (127 mm) |
| Media Sensor |
Transmissive (top and bottom sensor combination): gap, hole or notch |
| Media Thickness |
Thickness range: 0.0025” – 0.01” (0.06 – 0.25mm) |
| Media Width |
Width range: 0.75” – 4.40” (19 – 112mm) |
|
| Ribbon Characteristics |
| Ribbon Width |
1” – 4.3” (25mm – 109mm) |
| Core Inner Diameter |
Maximum outside diameter: 2.6” (65mm) – Core diameters: 0.5” (13mm) or |
|
| Performance Characteristics |
| Error Indicators |
Two Light Indicators with 3 Colors |
| Memory |
64MB Flash / 16MB DRAM |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:– Linear: Code 3 of 9, UPC-A, UPC-E, Interleaved 2 of 5 (I 2 of 5), Code 128, EAN-13, EAN-8, HBIC, Codabar, Interleaved 2 of 5 with a module 10 checksum, Plessey, Interleaved 2 of 5 with a module 10 checksum & shipping bearer bars, 2 digit UPC addendum, 5 digit UPC addendum, Code 93, Postnet, UCC/EAN Code 128, K-Mart NON EDI barcode, Telepen |
|
2D: Symbologies: UPS MaxiCode, FIM, PDF-417, DataMatrix, QR Code, Aztec, Code 128 with auto Subset Switching, GS1 Databar (replaced RSS), TCIF Linked Bar Code 3 of 9 (TLC39), MicroPDF 417 |
| Graphics |
PCX, .BMP, .IMG format files |
|
| Software |
| Driver / Utility |
– Drivers: Windows® XP, Windows® Vista, Windows® NT |
| SDK |
NETira CT: Configuration tool (Professsional models only) – DMX Config: Printer configuration tool (Basic and Advanced models only) – DMX Net Manager: Networked printer management tool (Advanced models only) – Embedded Configurator: Resident printer configuration tool |
|
| Environment Characteristics |
| Operating Environment |
40°F to 95°F (4°C to 35°C) |
| User Options |
Thermal transfer (includes 1” ribbon adaptors)High resolution (300 dpi)Wireless LAN field installable (Professional models only)Bluetooth® v2.0 field installable (Professional models only) Label (peeler) Dispenser w/Sensor field installable Cutter w/Sensor field installable (Not available on Basic) |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
8.01”w x 7.36”h x 11.10”d (203.5mm x187mm x 282mm) |
| Power Requirements |
Fitted Lower Enclosure for Power Converter (optional)Fitted Lower Enclosure for Power Converter & Battery Pack (accessory) |
| Weight |
5.25 lbs (2.4 kg) |
