| Printing Characteristics |
| Print Length |
1520 mm (59.8 in) at 203 dpi1028 mm (40.5 in) at 300 dpi |
| Print Method |
Direct thermal and thermal transfer |
| Print Speed |
50-150 mm/s (2-6 ips) at 203 dpi50-100 mm/s (2-4 ips) at 300 dpi |
| Print Width |
104 mm (4.09 in) at 203 dpi105.7 mm (4.16 in) at 300 dpi |
| Resolution |
8 dots/mm (203 dpi)11.8 dots/mm (300 dpi, option) |
|
| Media Characteristics |
| Media Core Diameter |
213 mm (8.38 in)38-76mm (1.5-3 in) |
| Media Sensor |
Gap, notch, black mark, continuous |
| Media Thickness |
Thickness: 2.3 to 9.8 mil |
| Media Type |
Labels & Tags |
| Media Width |
Max Width: 118.1 mm (4.65 in)Max Width with cutter: 114m (4.49 in)Min Width: 25.4 mm (1 in) |
|
| Ribbon Characteristics |
| Ribbon Roll Diameter |
76 mm (2.99 in) or approx. 450m |
| Ribbon Type |
Wax, mid-range, resin |
| Core Inner Diameter |
Core ID: 25.4 mm (1”) |
|
| Performance Characteristics |
| Indicators |
Four LED indicators: Power; Data Transfer; Error/Warning; Ready-to-Work |
| Interface |
Ethernet 10/100 MbpsRS-232, up to 115.2 kB/s |
| Memory |
Standard: 8MB Flash memory 16MB SDRAM (1Compact Flash slot and 1 USB Boot / Hub Slot)Available: Up to1GB CompactFlash (type 1) memory,Multi GB USB Thumb Drive Memory |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
All major 1D and 2D symbologies are supported |
| Graphics |
Supports PCX file format. (Fingerprint Only)Other formats supported with Label Generation Tools |
|
| Software |
| Driver / Utility |
InterDriver™ Windows printer driver Intermec label design and print package PrintSet for printer configuration |
| SDK |
IPLFingerprint/Direct ProtocolZSim (ZPL)DSim (DPL)ESim (EPL)XML enabled for SAP® AII and Oracle ® WMS |
|
| Environment Characteristics |
| Humidity |
Humidity: 20-85% non-condensing free air |
| Operation Environment |
Temperature: +5°to 40°C (+40°to 104°F) |
| User Options |
Internal rewinder, cutter, CompactFlash™ memorycards, parallel interface, real-time clock |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
Length: 453 mm (17.8 in)Height: 273 mm (10.8 in)Width: 270 mm (10.6 in) |
| Power Source |
Voltage Range: 100-240 VAC ±10% auto switchFrequency Range: 45-65 Hz |
| Weight |
13 kg (28.7 lbs) |
