| Printing Characteristics |
| Character Sets |
ESC/P: Standard: Extended Latin, Cyrillic, Greekand HebrewOptional: Simplified Chinese, Traditional Chinese,Japanese, Korean, Arabic and ThaiCSim (CPCL): Standard: Extended Latin, Cyrillic,Greek and HebrewOptional: Simplified Chinese, Traditional Chinese,Japanese, Korean, Arabic and ThaiXSim (Ex-PCL): Standard: Extended Latin, Cyrillic,Greek and HebrewOptional: Simplified Chinese, Traditional Chinese,Japanese, Korean, Arabic and Thai |
| Print Width |
Maximum print width: 72 mm (2.83 in) |
| Printing Method |
Printhead: Direct thermal |
| Printing Speed |
Up to 3 ips (76.2 mm/sec) |
| Resolution |
203 dpi (8 dots/mm) |
|
| Media Characteristics |
| Max OD |
Maximum Media OD: 1.6 in (40.64 mm) |
| Media |
Media length: Continuous |
| Media Thickness |
Thickness: 60 ?m to 100 ?m (2.36 mils to 4 mils) |
| Media Type |
Receipt media |
| Media Width |
79 mm to 80 mm (3.110 in to 3.149 in) |
| Roll Core Inner |
Core ID: 10 mm (0.4 in) |
|
| Performance Characteristics |
| AC Adapter |
100 to 240 VAC 10VDC@1.0A; meets CECEPS |
| Barcode Symbologies |
ESC/P: 1D: Codabar, Code 39, Code 128, UCC/ EAN-128, Interleaved 2 of 5, UPC-A, EAN13, EAN82D: PDF417CSim (CPCL): 1D: Codabar, Code 39, Code 128, UCC/EAN-128, Interleaved 2 of 5, UPC-A, UPC-E, EAN13,EAN8XSim (Ex-PCL): 1D: Codabar, Code 39, Code 128Subset A-C, UCC/ EAN-128, Interleaved 2 of 5, UPC/EAN/JAN2D: PDF417 |
| Battery |
Standard Battery: Rechargeable, removable,7.4V Li-Ion, 1620mAhSmart Battery: Rechargeable, removable, 7.4V Li-Ion,1620mAh. Includes integrated fuel gauge to monitorand report battery pack serial number and impedance |
| Battery Recharging |
approximately 240 minutesEndurance per fully charged battery at 6% printdensity: 89 m (292 ft) |
| Card Readers |
Magnetic Stripe Reader (MSR) 3 trackANSI/ISO 7810, 7811 standardsAAMVA, CA DVA, RAWOptional support for DES, TDES, and AES encryptionwith DUKPT key management. |
| Communication Modules |
Standard: USB full speed V2.0Optional: Bluetooth® (v2.0, Class II), IrDA, 802.11b/g |
| Graphics |
Supports user-defined fonts, graphics, includingcustom logos |
| Memory |
RAM: 16 MBFlash: 64 MB |
| Software |
Programming Language: ESC/P (Line Print and EasyPrint modes), CSim (CPCL) and XSim (Ex-PCL) |
| Wireless Security |
Authentication and Encryption Options: Static WEP(64 & 128), Dynamic WEP with EAP, WPA/TKIP (Presharedkey & Enterprise with EAP), WPA2/AES-CCMP(Pre-shared key & Enterprise with EAP)EAP Options: PEAP/MSCHAPv2, PEAP/GTC, TTLS/MSCHAPv2, TTLS/PAP, LEAP, EAP-FAST |
|
| Environment Characteristics |
| Drop Specification |
1.2m (4 ft.) drop to concrete perMIL STD 810G, 1.5m (5 ft.) multiple drops to concretewith optional environmental case. |
| Humidity (Operation) |
20% to 85% non-condensing |
| Humidity (Storage) |
5% to 95% non-condensing |
| Operation Temperature |
-10°C to 50°C (14°F to 122°F) |
| Sealing |
Rain & Dust Resistance: IP42, IP54 with optional environmental case |
| Storage Temperature/Charging Temperature |
-20°C to 60°C (-4°F to 140°F)without battery 0°C to 40°C (32°F to 104°F) |
|
| Physical Characteristics |
| Dimensions (W x H x D) |
Width: 127.20 mm (5.01 in)Height: 57.69 mm (2.27 in)Length: 156.10 mm (6.14) |
| Weight |
with battery, excluding media: 349 g (12.3 oz) |
|
| Options |
| Accessories |
Belt loopMetal belt clipShoulder strapIP54 protective environmental caseProtective bootPrinthead cleaning swabSpare batteryCigarette lighter adapter/12V vehiclebattery chargerFlexDock Modular docking system for on-boardcharging or spare battery charging |
| User Options |
Ships withPrinterStandard or smart batteryUniversal AC charger with six socket adapter plugsPlastic belt clipOne roll of media ( either 2” or 3”)Quick start users guide |
